4-4 2005 PDI: Softail Models
Windshield Installation: FLSTC
CAUTION
Be sure you position the windshield bracket notches in
the grooves in the mounting bushings. Incorrect mount-
ing could result in damage to the windshield.
1. See Figure 4-3. Lower the windshield into position care-
fully inserting the side brackets between the headlamp
and the passing lamp supports until the bottom notches
are seated in the lower bushing grooves.
2. Standing at the front of the vehicle, gently push the top of
the windshield toward the rear until the upper notches
fully engage the upper bushings.
SEATS AND PASSENGER STRAP
Refer to the Softail Models Owner’s Manual for seat and pas-
senger strap removal and installation instructions.
Figure 4-3. Windshield Mounting
o0138xox
