Harley-Davidson Dyna 2008 - Page 133

2.20DEBRIS DEFLECTOR
REMOVAL
See Figure 2-93. Remove three screws to detach debris
deflector from rear fork.
INSTALLATION
See Figure 2-93. Attach debris deflector to rear fork using three
screws. Tighten to 40-60 in-lbs (4.5-6.8 Nm).
sm02279
Figure 2-93. Debris Deflector Screws
2-62 2008 Dyna Service: Chassis
