Harley-Davidson Dyna 2008 - BOTTOM END SERVICE 3.10; ENGINE IN CHASSIS

3.10BOTTOM END SERVICE
ENGINE IN CHASSIS
Table 3-28. Engine In Chassis: Cam Compartment Service
COMPONENT REPAIR
PROCEDURES
SERVICE PROCEDURE
Remove parts to gain access to all components above cylinder deck. See
3.11 STRIPPING MOTORCYCLE FOR SERVICE.
Dissassemble top end. See 3.15 TOP END OVERHAUL: DISASSEMBLY.
Inspect and repair.BREATHER ASSEMBLY.
See 3.19 BREATHER ASSEMBLY.
Inspect and repair.ROCKER ARM SUPPORT PLATE.
See 3.20 ROCKER ARM SUPPORT PLATE.
Inspect and repair.PUSH RODS, LIFTERS AND COVERS.
See 3.21 PUSH RODS, LIFTERS AND
COVERS.
Disassemble bottom end. See 3.17 BOTTOM END OVERHAUL: DISASSEMBLY.
Inspect and repair.COVER AND CAM SUPPORT PLATE
See 3.25 COVER AND CAM SUPPORT
PLATE*.
Inspect and repair.OIL PUMP
See 3.26 OIL PUMP.
Assemble bottom end. See 3.18 BOTTOM END OVERHAUL: ASSEMBLY.
Assemble motorcycle. See 3.12 ASSEMBLING MOTORCYCLE AFTER SER-
VICE.
Note: * If no other work is to be done, you may advance to 3.18 BOTTOM END OVERHAUL: ASSEMBLY when this step is
completed during bottom end service.
