1
3
2
sm02195
1. Fuel gauge sender
2. Removal tab
3. Wiring clip
Figure 4-52. Fuel Gauge Sender
1
3
2
sm02192
1. Fuel pump and sender connector [141]
2. Screws (12)
3. Vent hose
Figure 4-53.Top Plate: FXDWG/FXDF
9
6
8
11
7
5
12
10
1
3
2
4
sm02196
Figure 4-54.Top Plate Torque Sequence:
FXDWG/FXDC/FXDF
2008 Dyna Service: Fuel System 4-27
