1.5BULB REQUIREMENTS
GENERAL
Use the table to identify the bulb location and part number.
Refer to Table 1-6.
NOTE
The speedometer, tachometer, odometer and indicator lamps
are illuminated with LEDs. LEDs are non-repairable.The entire
assembly must be replaced if an LED fails.
Table 1-6. Bulb Chart: 2008 Dyna Models
H-D
PART
NUMBER
CURRENT
DRAW
(AMPERAGE)
BULBS
REQUIRED
DESCRIPTIONLAMP
69838-085.0/4.582High beam/low beam (FXDF)Headlamp
68329-035.0/4.581High beam/low beam (all other models)
53438-920.321Position lamp international
68167-040.591Tail lampTail and stop lamp
68167-042.101Stop lamp
68167-040.591Tail lamp international
68167-042.101Stop lamp international
68168-892.25/0.592Front/runningTurn signal lamp
68163-841.752Front international
68572-64B2.252Rear
68163-841.752Rear international
Illuminated with LEDs. Replace entire assembly
upon failure.
High beam indicatorInstrument panel indicators
Oil pressure indicator
Neutral indicator
Turn signal indicators
Fuel Gauges: All models use an LED built into the gauge.
1-12 2008 Dyna Service: Maintenance
