NOTE
Brake pedal freeplay is built into master cylinder and no
adjustment is required.When pedal is pushed down with hand,
a small amount of freeplay must be felt.
5
4
3
2
1
5
4
3
2
1
sm02847
1. Rear brake master cylinder
2. Rubber boot
3. Push rod
4. Jam nut
5. Brake rod
Figure 1-8. Rear Brake Pedal Height (Top: FXDWG models,
Bottom: All models but FXDWG)
1-14 2008 Dyna Service: Maintenance
