Harley-Davidson Dyna 2008 - Page 333

2
1
4
3
sm02435
1. Mainshaft locknut wrench
2. Final drive sprocket locking tool
3. Rear fork pivot nut
4. 3/4 inch breaker bar
Figure 6-41. Sprocket Nut Installation (Typical)
1
2
3
45
o
sm02439
1. Transmission sprocket nut
2. Transmission sprocket
3. Line scribed
Figure 6-42.Transmission Sprocket Nut Final Tightening
6-20 2008 Dyna Service: Drive
