Harley-Davidson Dyna 2008 - Page 348

1
2
14
13
12
11
10
9
8
7
6
5
4
3
sm02484
8.1. Countershaft 1st gearMainshaft
2. 9.Countershaft Countershaft 2nd gear
10.3. Countershaft 3rd gearMainshaft 1st gear
4. 11.Mainshaft 2nd gear Countershaft 4th gear
12.5. Countershaft 5th gearMainshaft 3rd gear
6. 13.Mainshaft 4th gear Countershaft 6th gear
14.7. Screw extractorMainshaft 5th gear
Figure 7-16. Gear Set
2008 Dyna Service: Transmission 7-11
