11.1. Mounting blockHeadlamp housing
2. 12.Headlamp connector Vertical adjusting bolt
13.3. Headlamp housing connectorAdapter ring
4. 14.Boot Lockwasher
15.5. Bulb shieldClip
6. 16.Bulb Headlamp lens
17.7. Trim ringVertical adjusting nut
8. 18.Washer (2) Nut
19.9. ScrewLockwasher
10. Horizontal adjusting bolt
Figure 8-20. Single Bulb Headlamp
Dual Bulb Headlamp
1. See Figure 8-22. Remove two screws (1) and remove trim
ring (5).
2. Pull reflector assembly (4) away from the headlight housing
(2).
3. See Figure 8-21. Raise latch lock (1). Depress latch (2)
and disconnect connector.
Handle bulb carefully and wear eye protection. Bulb con-
tains gas under pressure, which, if not handled carefully,
could cause serious eye injury. (00062b)
4. Rotate bulb assembly counterclockwise to remove from
housing.
