M
A
D
E
I
N
U
S
A
HARLEY
-DAVIDSON
MILWAUKEE,WI53201
MADEIN U.S.A.
WARRANTYANDADJUSTMENT POLICY
T
h
i
s
b
a
t
t
e
r
y
w
i
l
l
b
e
r
e
p
l
a
c
e
d
w
i
t
h
o
u
t
c
h
a
r
g
e
iffound to be defectivein materials or
workmanship12 months from date of
vehiclepurchase or 6 months from date
ofover-the-counterpurchase. After 6
months,but within the 12 months of the
o
v
e
r
-
t
h
e
-
c
o
u
n
t
e
r
p
u
r
c
h
a
s
e
,
t
h
e
b
a
t
t
e
r
y
w
i
l
l
bereplaced and the purchaser charged
o
n
l
y
f
o
r
t
h
e
p
e
r
i
o
d
o
f
o
w
n
e
r
s
h
i
p
b
a
s
e
d
o
n
theregular price at the time of return
proratedver the numberof months of
w
a
r
r
a
n
t
y
.
T
h
i
s
w
a
r
r
a
n
t
y
i
s
n
o
t
t
r
a
n
s
f
e
r
a
b
l
e
andis voided bythe use of rejuvenators,
improperelectrolyte, neglect or abuse.
P
ARTNO
.
1 2 3 4 5 6 7 8 9 0
JA FE MA AP MY JU JY AU SE OC NO DE
4
3
6
1
2
5
sm02476
1. Screw
2. Cover
3. Battery tray
4. Negative battery terminal
5. Positive battery terminal
6. Battery strap
Figure 1-39. Battery Assembly
STORAGE
TOOL NAMEPART NUMBER
GLOBAL BATTERY CHARGER99863-01A
Batteries contain sulfuric acid, which could cause severe
burns to eyes and skin. Wear a protective face shield,
rubberized gloves and protective clothing when working
with batteries. KEEP BATTERIES AWAY FROM CHILDREN.
(00063a)
Do not allow battery to completely discharge.The electro-
lyte in a discharged battery will freeze. The more dis-
charged a battery is, the more easily it can freeze and crack
the battery case. (00218a)
If the motorcycle is to be stored with the security system armed,
connect a GLOBAL BATTERY CHARGER (Part No. 99863-
01A) to maintain battery charge.
If the motorcycle is to be stored with the battery installed, a
GLOBAL BATTERY CHARGER unavailable, and with the
security system not armed, unplug the maxi-fuse.
If the motorcycle will not be operated for several months, such
as during the winter season, remove the battery from the
motorcycle and fully charge.
See Figure 1-40. Self-discharge is a normal condition and
occurs continuously at a rate that depends on the ambient
temperature and the battery's state of charge. Batteries dis-
charge at a faster rate at higher ambient temperatures. To
reduce the self-discharge rate, store battery in a cool (not
freezing), dry place.
Charge the battery every month if stored at temperatures below
60° F (16° C). Charge the battery more frequently if stored in
a warm area above 60° F (16° C).
NOTES
• The GLOBAL BATTERY CHARGER (Part No. 99863-01A)
may be used to maintain battery charge for extended
periods of time without risk of overcharging or boiling.
• When returning a battery to service after storage, see
ELECTRICAL DIAGNOSTIC MANUAL.
1. Capacity
2. Months of stand
Figure 1-40. Battery Self-Discharge Rate
INSTALLATION AND CONNECTION
Do not over-tighten bolts on battery terminals. Use
recommended torque values. Over-tightening battery ter-
minal bolts could result in damage to battery terminals.
(00216a)
Connect positive (+) battery cable first. If positive (+) cable
should contact ground with negative (-) cable connected,
the resulting sparks can cause a battery explosion, which
could result in death or serious injury. (00068a)
NOTE
Check that battery is fully charged before installation.
1. See Figure 1-39. With battery terminals facing outward,
place battery in battery tray and install battery strap.
2. Insert fastener through battery positive cable terminal and
into threaded hole of battery positive (+) terminal (5).
Tighten fastener to 60-96 in-lbs (6.8-10.9 Nm). Place
battery terminal cover over positive battery terminal.
3. Insert fastener through battery negative cable terminal
into threaded hole of battery negative (-) terminal (4).
Tighten fastener to 60-96 in-lbs (6.8-10.9 Nm).
4. Apply a light coat of petroleum jelly or corrosion retardant
material to both battery terminals.
1-36 2008 Dyna Service: Maintenance
