1.25ENGINE MOUNTS
INSPECTION
1. See Figure 1-50. Check for cracks or tears in the isolator
rubber.
2. Check stabilizer links for wear.
3. Check that all engine mount bolts are tight.
4. Check that all engine mount rivets are not sheared.
5. Check that the mounts are supporting the weight of the
motor.
17
18
12
6
8
1
17
6
16
10
3
14
6
7
2
4
5
15
21
13
19
9
11
20
sm02288
12.1. BoltBolt
2. 13.Lockwasher Lockwasher
14.3. WasherWasher
4. 15.Front isolator Bolt
16.5. SpacerBolt
6. 17.Flange nut Washer (3)
18.7. Stabilizer linkWasher
8. 19.Rear isolator Washer
20.9. BoltBolt
10. 21.Flange nut Bolt
11. Washer
Figure 1-50. Engine Mounts
2008 Dyna Service: Maintenance 1-47
