Harley-Davidson Dyna 2008 - Page 96

sm03321
Figure 2-50. Lower Row Spokes Completed
9. See Figure 2-51. Insert any upper row spoke into hub and
angle spoke counterclockwise into appropriate rim hole.
Install remaining upper row spokes.
sm03322
Figure 2-51. Upper Spoke Row Completed
10. Tighten spoke nipples to the torque specification listed in
Table 2-13.
11. True wheel. See 2.9 TRUING LACED WHEELS.
Table 2-13. Spoke Nipple Torque Specification
MINIMUM TORQUERIM TYPE
55 in-lbs (6.2 Nm)All
2008 Dyna Service: Chassis 2-25
