Harman Kardon AVR 225 Quick Start Guide

AVR 225 QUICK-START GUIDE
SURROUND
RIGHT SPEAKER
SURROUND
LEFT SPEAKER
FRONT RIGHT
SPEAKER
FRONT LEFT
SPEAKER
CENTER SPEAKER
SUBWOOFER
+
_
LINE IN/SUB/LFE
+
_
+
_
+
_
+
_
, 1A
, 0.5A
SPEAKER CONNECTIONS
Figure 2 – Speaker Connections
Figure 3 – How to Use the Binding-Post
Speaker Terminal
Step 2. Connect the speakers to the receiver: Red (+)
on speaker to colored (+) on receiver and
black (–) to black (–). (See page 14.)
Step 3. Connect the Subwoofer Pre-Out jack to
the Line-In jack on your subwoofer (see
page 16).Adjust the settings on the
subwoofer as needed.

Harman Kardon AVR 225 Specifications
