Harman Kardon AVR 247 User Manual

22
SPEAKER PLACEMENT
Left Speaker Output. You will then need to follow the directions
in the Advanced Features section for manual setup of the sur-
round back speaker.
Subwoofer Placement
The subwoofer’s location is less critical, since low-frequency sounds are
omnidirectional. Placing the subwoofer close to a wall or in a corner will
reinforce the low frequencies, and may create a “boomy” sound. You
may wish to experiment over time by placing the subwoofer where the
listener normally sits and then walking around the room until the low
frequencies sound best. Place the subwoofer in that spot.
NOTE: Your receiver will sound its best when the same model
loudspeaker is used for all positions (other than the subwoofer).
If that isn’t possible, try to use speakers made by the same
manufacturer.
AVR247om.qxd 7/10/07 1:05 PM Page 22

Harman Kardon AVR 247 Specifications

General

Number of Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
Type	AV Receiver
Signal-to-Noise Ratio	100 dB
Input Sensitivity	200mV
Input Impedance	47k ohms
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs (Optical)	2
Digital Audio Inputs (Coaxial)	2
Analog Audio Inputs	5
Total Harmonic Distortion	0.07%
Composite Video Inputs	4
Composite Video Outputs	1
Ethernet Port	No
USB Port	No
Wi-Fi	No
Bluetooth	No
Power Output	50W
Output Power	50 watts per channel (8 ohms, 20Hz-20kHz, 0.07% THD)
Frequency Response	10Hz – 100kHz (+0dB, –3dB)
Surround Sound Formats	Dolby Digital, DTS
