Harman Kardon AVR 247 User Manual

7
INTRODUCTION
Audio Inputs
• AM/FM/XM
®
* tuner
• CD
• Tape
• 6-/8-Channel direct
• /DMP for iPod** connectivity with audio/video playback
Audio/Video Inputs (With S-Video)
• Video 1
• Video 2
• Video 3
• Video 4 (on front panel)
• DVD
• Three assignable 100MHz component video inputs
• Simplay HD
™
-verified HDMI
™
1 and 2 (with audio/video processing
and 1080p pass-through)
• DCDi
®
by Faroudja video processing
Transcodes composite and S-video to component video
Transcodes 480i video to HDMI format, with upscaling up to 720p
Upgraded graphic text-based on-screen displays
Digital Audio Inputs
• Coaxial: two rear-panel/one front-panel
• Optical: two rear-panel/one front-panel
Outputs
• 7.1-Channel preamp outputs
• Tape (analog audio)
• Video 1 (analog audio and video)
• Video monitor (composite, S-video and component)
• Digital audio (one coaxial, one optical)
• Simplay HD-verified HDMI
• Multiroom audio: speaker- and line-level (shared with surround
back channels)
• Headphone
Ease of Use
• EzSet/EQ
™
automated setup (microphone supplied)
• Graphic on-screen display with HDMI, component, composite
and S-video
• Two-line dot-matrix front-panel display
• Color-coded connections
• Programmable 11-device main remote control
• Source input renaming
• A/V Sync Delay
• RS-232 serial port for system upgrades
• Switched accessory power outlet
• Remote infrared (IR) input and output
• Multiroom IR input
The AVR 247 is Simplay HD-verified for compatibility
via the HDMI connection with other Simplay HD-verified products.
Supplied Accessories
The following accessory items are supplied with the AVR 247. If any
of these items are missing, please contact Harman Kardon customer
service at www.harmankardon.com.
• System remote control
• EzSet/EQ microphone
• AM loop antenna
• FM wire antenna
• Three AAA batteries
• Two covers for front-panel jacks
The
Brid
g
e
TM
*XM antenna module and subscription to XM service required. Hardware and
service sold separately. XM service is not available in Alaska or Hawaii.
**Compatible with all iPod models equipped with a dock connector. Not compatible
with iPod shuffle models. Images and videos stored on iPod photo and video
models may be viewed.
COM
AVR247om.qxd 7/10/07 1:05 PM Page 7

Harman Kardon AVR 247 Specifications

General

Number of Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
Type	AV Receiver
Signal-to-Noise Ratio	100 dB
Input Sensitivity	200mV
Input Impedance	47k ohms
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs (Optical)	2
Digital Audio Inputs (Coaxial)	2
Analog Audio Inputs	5
Total Harmonic Distortion	0.07%
Composite Video Inputs	4
Composite Video Outputs	1
Ethernet Port	No
USB Port	No
Wi-Fi	No
Bluetooth	No
Power Output	50W
Output Power	50 watts per channel (8 ohms, 20Hz-20kHz, 0.07% THD)
Frequency Response	10Hz – 100kHz (+0dB, –3dB)
Surround Sound Formats	Dolby Digital, DTS
