Harman Kardon AVR 2600 Service Manual

TMP92FD28
2007-01-30
92FD28-3
(20) Clock controller
x Built-in two blocks of clock doubler (PLL). PLL supplies 48 MHz for USB and 36 MHz for CPU
from 9MHz
x Clock gear function: Select high-frequency clock fc to fc/16
x Special timer for CLOCK (fs = 32.768 kHz)
(21) Operating voltage
x External I/O Vcc = 3.0 to 3.6 V
x Internal V
CC
1.4 V to 1.6 V (fc max = 40 MHz)
(22) Package
x 100-pin QFP: P-LQFP100-1414-0.50F (TMP92FD28FG)
P-QFP100-1420-0.65A (TMP92FD28DFG)
