Table A2 – Source Setting Defaults
Appendix – Default settings, worksheets, remote product codes
Table A1 – Recommended Source Component Connections
Cable/Sat Blu-ray
Media
Server
Radio TV Game AUX The Bridge
DVR
(AVR 2650/
AVR 265 only)
USB
(AVR 3650/
AVR 365 only)
Surround Modes
(Auto Select)
Logic 7
Movie
Logic 7
Movie
Logic 7
Movie
Logic 7
Movie
Logic 7 Movie
Logic 7
Movie
Logic 7 Music Logic 7 Music Logic 7 Movie Stereo
Video Input HDMI 2 HDMI 1 HDMI 4 N/A
HDMI 5 (AVR
3650/AVR 365);
HDMI 1 (AVR
2650/AVR 265)
HDMI 3
HDMI Front (AVR
3650/AVR 365);
N/A (AVR 2650/
AVR 265)
The Bridge III HDMI 5 N/A
Audio Input HDMI 2 HDMI 1 HDMI 4 N/A
HDMI 5 (AVR
3650/AVR 365);
HDMI 1 (AVR
2650/AVR 265)
HDMI 3
HDMI Front (AVR
3650/AVR 365);
Analog 2 (AVR
2650/AVR 265)
The Bridge III HDMI 5 N/A
Resolution to
Display*
480i (NTSC);
576p (PAL)
480i (NTSC);
576p (PAL)
480i (NTSC);
576p (PAL)
480i (NTSC);
576p (PAL)
480i (NTSC);
576p (PAL)
480i (NTSC);
576p (PAL)
480i (NTSC);
576p (PAL)
480i (NTSC);
576p (PAL)
480i (NTSC);
576p (PAL)
480i (NTSC);
576p (PAL)
Audio Auto Polling Off Off Off N/A Off Off Off N/A Off N/A
Zone 2 Audio — — — Radio — — Analog 2 The Bridge III — USB
Dolby Volume Medium Low Medium Medium Medium Medium Low Medium Medium Medium
* Video output resolution may vary for HDMI connections. The default HDMI resolution is 1080i for NTSC and PAL.
Device Type AVR Source Digital Audio Connection Analog Audio Connection Video Connections
Cable TV, satellite TV, HDTV
or other device that delivers
television programs
Cable/SAT HDMI 2 Analog 1, 2 or 3 HDMI 2
DVD Audio/Video, SACD,
Blu-ray Disc, HD-DVD player
Blu-ray HDMI 1 Analog 1, 2 or 3 HDMI 1
Media Server, including
Harman Kardon DMC 1000
Media Server HDMI 4 Analog 1, 2 or 3 HDMI 4
TV TV
HDMI 5 (AVR 3650/AVR 365);
HDMI 1 (AVR 2650/AVR 265)
Analog 1, 2 or 3
HDMI 5 (AVR 3650/AVR 365);
HDMI 1 (AVR 2650/AVR 265)
Video-game console Game
HDMI 3 (or HDMI front on
AVR 3650/AVR 365)
Analog 1, 2 or 3 4
HDMI 3 (or HDMI front on
AVR 3650/AVR 365)
Any audio or video device,
e.g., CD player, camcorder,
cassette deck
AUX Coaxial or Optical Analog 1, 2 or 3
Composite Video 1 or 2 (not used
for audio-only devices)
Recorder Any
Coaxial or Optical Input and
Optical Output
Analog 1, 2 or 3 Inputs and Rec
Out
Composite Video 2 Input and
Output
iPod or iPhone The Bridge IIIP None The Bridge IIIP
The Bridge IIIP for photo- and
video-capable iPod and iPhone
models
DVR
(AVR 2650/AVR 265 only)
DVR HDMI 5 Analog 1, 2 or 3 HDMI 5
Appendix
