RS-232 Codes for AVR 7200/525/325
Remote Command AVR Function RS-232 Command
COMMENTS
Power On Power On 80 70 C0 3F
Power Off Power Off 80 70 9F 60
Mute Mute 80 70 C1 3E
AVR AVR Power On 80 70 C0 3F
DVD INPUT SEL 80 70 D0 2F
CD INPUT SEL 80 70 C4 3B
TAPE INPUT SEL 80 70 CC 33
VID1(VCR) VID1 80 70 CA 35
VID2(TV) VID2 80 70 CB 34
VID3(CBL/SAT) VID3 80 70 CE 31
VID4 VID4 80 70 D1 2E
AM/FM AM/FM 80 70 81 7E
6CH/8CH 6CH/8CH 82 72 DB 24
The first transmission of this code shows the current mode. Subsequent
transmissions step through the available modes.
Sleep/ CH+ Sleep 80 70 DB 24
Test Tone Test Tone 82 72 8C 73
Vol Up Vol Up 80 70 C7 38
Surr/CH- Surr 82 72 58 A7
Initiates surround mode choice and displays current mode
Surr \/ 82 72 86 79
Scroll down through surround choices (Down Arrow)
Surr /\ 82 72 85 7A
Scroll up through surround choices (Up Arrow)
Night Night 82 72 96 69
Multi-Room Multi-Room 82 72 DF 20
Accesses the Multiroom menu and displays current status
MR \/ 82 72 5F A0
Scroll down through Multiroom choices (Down Arrow)
MR /\ 82 72 5E A1
Scroll up through Multiroom choices (Up Arrow)
Vol Down Vol Down 80 70 C8 37
CH. / Guide Channel 82 72 5D A2
Accesses the Channel Trim settings menu
Level-/Down Level-/Down 82 72 9A 65
Decreases the Channel Trim Level
Level+/Up Level+/Up 82 72 99 66
Increases the Channel Trim Level
Speaker / Menu Speaker 82 72 53 AC
Access the Speaker Configuration Menu
Speaker \/ 82 72 8F 70
Scrolls down through the speaker configuration choices
Speaker /\ 82 72 8E 71
Scrolls up through the speaker configuration choices
Down \/ Down \/ 82 72 9A 65
Down directional movement when navigating through OSD Menus
Left < Left < 82 72 C1 3E
Left directional movement used when navigating through the OSD Menus
SET SET 82 72 84 7B
Right > Right > 82 72 C2 3D
Right directional movement when navigating through OSD Menus
Up /\ Up /\ 82 72 99 66
Up directional movement when navigating through OSD Menus
Digital / Exit Digital 82 72 54AB
Accesses Digital Input Menu and displays input for current source
Digital \/ 82 72 56A9
Scrolls down through the list of digital inputs
Digital /\ 82 72 57 A8
Scrolls up through the list of digital inputs
Delay / Prev. CH Delay 82 72 52 AD
Accesses Delay Settings
Delay \/ 82 72 8B 74
Scrolls down through delay settings
Delay /\ 82 72 8A 75
Scrolls up through delay settings
1 1 80 70 87 78
2 2 80 70 88 77
3 3 80 70 89 76
4 4 80 70 8A 75
5 5 80 70 8B 74
6 6 80 70 8C 73
7 7 80 70 8D 72
8 8 80 70 8E 71
9 9 80 70 9D 62
0 0 80 70 9E 61
TUN-M TUN-M 80 70 93 6C
Memory Memory 80 70 86 79
Tuning Up Tuning Up 80 70 84 7B
Direct Direct 80 70 9B 64
Clear Clear 82 72 D9 26
Preset Up Preset Up 82 72 D0 2F
Tuning Down Tuning Down 80 70 85 7A
OSD OSD 82 72 5C A3
D. Skip D. Skip 82 72 DD 22
Preset Down Preset Down 82 72 D1 2E
Dolby Dolby 82 72 50 AF
DTS Surround DTS Surround 82 72 A0 5F
DTS NEO:6 DTS NEO:6 82 72 A1 5E
Logic7 Logic7 82 72 A2 5D
Stereo Stereo 82 72 9B 64
Revision 1.1
1/6/2003
