AVR 340 AUDIO/VIDEO RECEIVER
3 I
ntroduction
4 I
mportant Safety Information
4 U
npacking
5 Front-Panel Controls
8 Rear-Panel Connections
11 Main Remote Control Functions
15 Zone II Remote Control Functions
16 Installation and Connections
19 System Configuration
19 Speaker Selection and Placement
21 System Setup
2
1
U
sing the On-Screen Display
2
2
I
nput Setup
2
3
A
udio Setup
23 Surround Setup
26 Automated Speaker Setup Using EzSet/EQ
28 Manual Setup
28 Speaker Size
30 Speaker Crossover Settings
30 Delay Settings
31 Output Level Adjustment
34 Operation
34 Basic Operation
34 Source Selection
34 6-Channel/8-Channel Direct Input
34 Volume and Tone Control
35 Surround Mode Selection
36 Surround Mode Chart
38 Digital Audio Playback
40 Surround Mode Availability for Incoming Bitstreams
41 Tuner Operation
42 Recording
42 Using
42 Output Level Trim Adjustment
42 Dim Function
44 Advanced Features
46 Multiroom Operation
48 Programming the Main Remote
48 Programming Device Codes
48 Macro Programming
49 Programmed Device Functions
50 V
olume Punch-Through
50 Channel Control Punch-Through
50 Transport Control Punch-Through
50 Resetting the Remote Memory
51 Function List
53 Setup Code Tables
63 Troubleshooting Guide
63 Processor Reset
64 Technical Specifications
64 Trademark Acknowledgements
65 Index
66 Appendix – Settings Worksheet
2 TABLE OF CONTENTS
Typographical Conventions
In order to help you use this manual with the remote control, front-panel controls and rear-panel connections,
certain conventions have been used.
EXAMPLE – (bold type) indicates a specific remote control or front-panel button, or rear-panel
connection jack
EXAMPLE – (OCR type) indicates a message that is visible on-screen or on the front-panel
infor
mation display
1 – (number in a square) indicates a specific front-panel control
¡ – (number in a circle) indicates a rear
-panel connection
a – (number in an oval) indicates a button or indicator on the remote
å
– (letter in an oval) indicates a button on the Zone II remote
The appearance of the text or cursor for your receiver’s on-screen menus may vary slightly from the
illustrations in this manual.
Whether the text appears in all uppercase or upper
- and lowercase characters
,
performance and operation remain the same.
For Canadian model
Modèle pour les Canadien
C
et appareil numérique de la classe B est conforme
à la norme NMB-003 du Canada.
S
ur les modèles dont la fiche est polarisee:
ATTENTION: Pour éviter les chocs électriques, introduire
la lame la plus large de la fiche dans la borne
correspondante de la prise et pousser jusqu’au fond.
This class B digital apparatus complies with Canadian
I
CES-003.
For models having a power cord with a polarized plug:
C
AUTION: To prevent electric shock, match wide blade
of plug to wide slot, fully insert.
Please register your product on our Web site at
www
.harmankardon.com. Note: You’ll need the
product’
s serial number
.
At the same time
,
you can
choose to be notified about our new products and/or
special promotions.
