Harman Kardon AVR 350/230 - Page 68

POWER PCB ASSY
Ref. # Part Number
Description
Value
VR85 HVN1RA221B01T RES , SEMI FIXED(220 OHM) RH0615C100221
VR86 HVN1RA221B01T RES , SEMI FIXED(220 OHM) RH0615C100221
VR87 HVN1RA221B01T RES , SEMI FIXED(220 OHM) RH0615C100221
BN17 CJP12GB143ZB PIN HEADER , DIP SOCKET PIN HEADER
BN20 CWB1C905220BM WIRE ASS'Y 2.5MM PITCH, 220M
M
BN22 CWB1C902280NN WIRE ASS'Y WIRE
BN95 CWB1C903080EN WIRE ASS'Y WIRE
BN96 CWB1C909150BM WIRE ASS'Y WIRE
BN99 CWB1B908270EN WIRE ASS'Y WIRE
CN13 CJP05GA01ZY CON WAFER YMW025-05R WAFER
CN19 CJP03GA90ZY WAFER WAFER
CN20 CJP04GA90ZM WAFER WAFER
CN31 CJP02GA19ZY WAFER, 2PIN CJP02GA19ZY
CN32 CJP02GA19ZY WAFER, 2PIN CJP02GA19ZY
CN33 CJP02GA19ZY WAFER, 2PIN CJP02GA19ZY
CN34 CJP02GA19ZY WAFER, 2PIN CJP02GA19ZY
CN35 CJP02GA19ZY WAFER, 2PIN CJP02GA19ZY
CN36 CJP02GA19ZY WAFER, 2PIN CJP02GA19ZY
CN37 CJP02GA19ZY WAFER, 2PIN CJP02GA19ZY
CN81 CJP08GA01ZY WAFER, STRAIGHT, 8PIN WAFER
CN88 CJP06GA19ZY WAFER, STRAIGHT, 6PIN WAFER
CN96 CJP09GA01ZY CON WAFER YMW025-09R WAFER
CN98 HJP08GB131ZK WAFER WAFER
C122 CCEA1JH101E CAP , ELECT 100UF 63V
C124 CCEA1VH102E CAP , ELECT 1000UF 35V
C128 CCEA1EH102E CAP , ELECT 1000UF 25V
C129 CCEA1EH222E CAP , ELECT 2200UF 25V
C132 CCEA1EH822F CAP, ELECT(8200uF/25V) 8200uF/25V
C912 CCEA0JKR3222E CAP , ELECT 2200UF 6.3V
C929 CCEA1VH102E CAP , ELECT 1000UF 35V
C930 CCEA1VH102E CAP , ELECT 1000UF 35V
C941 CCEA1CH682E CAP , ELECT 6800UF 16V
C951 CCEA1HH102E CAP , ELECT 1000UF/50V
D120 HVDSB2100 DIODE , SCHOTTKY SB2100
D121 HVDSB2100 DIODE , SCHOTTKY SB2100
D991 CVDKBU804FMA BRIDGE DIODE ASS'Y KBU804F
CMY1A219 HEAT SINK (BRIDGE DIODE) HEAT SINK
CTB3+12JR SCREW SCREW
HVDKBU804F DIODE , BRIDGE KBU804F
K8AYG6260 COMPOUND , SILICONE SILICONE
D992 CVDKBU804FMA BRIDGE DIODE ASS'Y KBU804F
CMY1A219 HEAT SINK (BRIDGE DIODE) HEAT SINK
CTB3+12JR SCREW SCREW
HVDKBU804F DIODE , BRIDGE KBU804F
harman/kardon
AVR 347/230 - AVR 350/230 Service Manual
Page 68 of 95
