25
INSTALLATION
Source Device Type AVR 350 Source Input Audio Connections Video Connections
VCR, DVR, PVR, Video 1 • Video 1 Analog (inputs and outputs) •
One
of Component Video 2, Video 1 S-video
TiVo or other and
or
Video 1 Composite Video Input
audio/video recorder • Any one available coaxial or optical digital, • For recording, use Video 1 S-video
or
audio input, with corresponding coax Composite Video Output, and do not use
or optical digital output component video connections at all
Cable TV, satellite TV, Video 2 • Video 2 Analog Inputs and •
One
of Component Video 3, Video 2
HDTV or other • Optical 1 Input S-video
or
Video 2 Composite Video Input
device that delivers
television programs
TV or other audio/video Video 3 • Video 3 Analog Inputs and • Video 3 S-video
or
Video 3 Composite
device (only when used • Any one available coaxial or optical Video Input
as a source) digital audio input • Not required if source is a TV
TV, game console, Video 4 (front-panel jacks) • Video 4 Analog Inputs
and • Video 4 S-video
or
Video 4 Composite Video
camera or other •
Either
Coax 3
or
Optical 3 Input Input
audio/video device • Not required if source is a TV
DVD Audio/Video, DVD • DVD Analog Inputs • Component Video 1 Input
SACD, HD-DVD, • 6-/8-Channel Inputs (optional) and
Blu-ray Disc • Coax 1 Input
HDMI-capable DVD HDMI 1 • HDMI 1 Input • HDMI 1 Input
Audio/Video or HD-DVD • If the source only outputs video via HDMI,
player or other audio/ use any one available coaxial or
video device optical digital audio input
HDMI-capable DVD HDMI 2 • HDMI 2 Input • HDMI 2 Input
Audio/Video or HD-DVD • If the source only outputs video via HDMI,
player or other audio/ use any one available coaxial or
video device optical digital audio input
CD player CD • CD Analog Inputs
and • Not required
• Any one available coaxial or optical
digital audio input
CDR, MiniDisc, Tape • Tape Analog (inputs and outputs) and • Not required
cassette • Any one available coaxial or optical digital,
audio input, with corresponding output
or optical digital output
Table 2 – Recommended Source Component Connections
For each video source, select one type of video connection. HDMI video
is preferred, but both your source device and your video display must
have this type of video capability. If either device does not, then use
component video, S-video or composite video.
Referring to Table 2, we recommend that you connect the DVD source
to the Component Video 1 inputs, the Video 1 source to the Component
Video 2 inputs, and the Video 2 source to the Component Video 3 inputs.
Any HDMI-capable source devices should be connected to one of the
two HDMI inputs. All other source devices should be connected to either
the component, S- or composite video input for that source. However,
you may make whatever video connections are best for your system.
NOTE: It’s possible for a source to use none of the connections
named for that source. For example, you might connect your
DVD player to the Component Video 1 inputs and the Coax 1
digital audio input. However, we will refer to this source as
“DVD,” and in the Initial Setup section you will program the
receiver so that these connections are assigned to the DVD
source. When you select “DVD” as your source using the front
panel or the remote, the correct connections for your DVD
player will be used.
We recommend connecting your various sources using the connections
shown in Table 2 (below) in order to simplify programming your receiver
and remote control. However, you may connect any device to any
source input.
AVR350 om.qxd 8/29/07 9:58 AM Page 25
