Harman Kardon AVR 355 Service Manual

FRONT PANEL ASSY
Ref. # Part Number Description Value
CB72 CWC4F2A17A280B CABLE , CARD(17P, 280mm) CARD CABLE
BOTTOM CHASSIS ASS'Y
Ref. # Part Number Description Value
CUAAVR355/230 BOTTOM CHAASIS ASS'Y ASS'Y
CHD1A012ZR SCREW , SPECIAL SCREW
CHD1A023R SCREW , SPECIAL SCREW
CHD4A012R SCREW , SPECIAL SCREW
CHE170 HOLDER , PCB HOLDER
CHE36-3 CLAMPER , WIRE CLAMPER
CHG1A104Z CUSHION , RUBBER CUSION
CHG1A160Z CUSHION , RUBBER CUSION
CHG1A373 CUSHION , FOOT AVR350 CUSION
CHG1A412 CUSHION CUSION
CHS1A032 TAPE , HEMELON TAPE
CKF8A337Z PANEL , REAR AVR355/230 PANEL
CKL1A094 FOOT , A AVR350 FOOT
CKL1A095 FOOT , B AVR350 FOOT
CMD1A636 BRACKET , PCB BRACKET
CMD2A487 BRACKET , TRANS BRACKET
CNVM9014MS171L MODULE , TUNER(EUR) TUNER
CTB3+10JFZR SCREW SCREW
CTB3+6FFZR SCREW SCREW
CTB3+6JR SCREW SCREW
CTB3+8JR SCREW SCREW
CTS3+8JFZR SCREW SCREW
CTW3+12JR SCREW SCREW
CTW3+8JR SCREW SCREW
CUA1A282 CHASSIS , BOTTOM AVR255 CHASSIS
BN90 CSHAVR155ZA MOMS SW ASS'Y SW ASS'Y
CSH1A009ZV SWITCH , MOMS SWITCH
CWZAVR255ZA WIRE , ASS'Y(2P,150mm) WIRE
BN92 CWZSR4001BN91A WIRE ASS'Y WIRE
CLZ9W003Z FERRITE , RING 29X7.7X19
CWZSR4001BN91 WIRE ASS'Y WIRE
CB11 CWC4F2A17A100B CABLE , CARD(17P, 100MM, 1MM, B-TYPE) CARD CABLE
CB12 CWC1C4A21B110B CABLE , CARD CARD CABLE
CB13 CWC4C4A13B100B CABLE , CARD CARD CABLE
CB14 CWC4F2A17A100B CABLE , CARD(17P, 100MM, 1MM, B-TYPE) CARD CABLE
CB15 CWC4F2A17A120B CABLE , CARD(17P, 120mm) CARD CABLE
CB16 CWC4F2A13A100B CABLE , CARD(13P, 100mm) CARD CABLE
CB19 CWC4F2A07A080B CABLE , CARD(7P, 80mm, B TYPE) CARD CABLE
CB47 CWC4F2A07A120B CABLE , CARD (7P, 120MM, 1MM) CARD CABLE
F901 KBA2C6300TLEZ FUSE(233TYPE, 6.3A,250V) LITTEL FUSE
RC91 CJJ8A006ZW RECEPTACLE , AC(15A/250V,R-301,B21) INNET
T901 CLT5W033ZE TRANS , POWER AVR355/230 MAINTRANS
FRONT PCB ASSY
Ref. # Part Number Description Value
COP12053J AVR355/230 FRONT PCB ASS'Y ASS'Y
C714 CCBS1H151KBT CAP , CERAMIC(150PF/50V) 150UF 50V K
C716 CCEA1AH331T CAP , ELECT 330UF 10V
C719 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) 1000PF 50V K
C720 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) 1000PF 50V K
C721 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) 1000PF 50V K
C723 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C728 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C729 CCBS1H473ZFT CAP , CERAMIC(47000PF/50V) 0.047UF 50V Z
C735 CCEA1CKS100T CAP , ELECT 10UF 16V
C742 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V Z
harman/kardon
AVR 355/230 Service Manual
Page 10 of 125
