Harman Kardon AVR 355 Service Manual

FRONT PCB ASSY
Ref. # Part Number Description Value
C793 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C794 CCBS1C222MXT CAP , CERAMIC(2200PF/16V) 2200PF 16V
C795 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) 1000PF 50V K
C796 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) 1000PF 50V K
C805 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V Z
C806 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V Z
C807 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C808 CCBS1H181KBT CAP , CERAMIC(180PF/50V) 180PF 50V
C809 CCEA1AH471T CAP , ELECT 470UF 10V
C812 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C817 CCBS1H100JCT CAP , CERAMIC(10PF/50V) 10PF 50V
C820 CCEA1HH100T CAP , ELECT 10UF 50V
C821 CCEA1EH470T CAP , ELECT 47UF 25V
C822 CCEA1EH470T CAP , ELECT 47UF 25V
C823 CCEA1HH100T CAP , ELECT 10UF 50V
C824 CCBS1H471KBT CAP , CERAMIC(470PF/50V) 470PF 50V
C825 CCBS1H151KBT CAP , CERAMIC(150PF/50V) 150PF 50V
C828 CCBS1H470JT CAP , CERAMIC(47PF/50V) 47PF 50V
C830 CCBS1H473ZFT CAP , CERAMIC(47000PF/50V) 0.047F 50V
C841 CCEA1HH100T CAP , ELECT 10UF 50V
C842 CCEA1HH100T CAP , ELECT 10UF 50V
C843 CCEA1HH100T CAP , ELECT 10UF 50V
C850 CCBS1H471KBT CAP , CERAMIC(470PF/50V) 470PF 50V
C851 CCBS1H471KBT CAP , CERAMIC(470PF/50V) 470PF 50V
C852 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C855 CCBS1H101KBT CAP , CERAMIC(100PF/50V) 100PF 50V K
C856 CCBS1H101KBT CAP , CERAMIC(100PF/50V) 100PF 50V K
C857 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C862 CCBS1H101KBT CAP , CERAMIC(100PF/50V) 100PF 50V K
C863 CCBS1H101KBT CAP , CERAMIC(100PF/50V) 100PF 50V K
C866 CCEA1HH100T CAP , ELECT 10UF 50V
C867 CCEA1HH100T CAP , ELECT 10UF 50V
C868 CCEA1EH470T CAP , ELECT 47UF 25V
C869 CCEA1EH470T CAP , ELECT 47UF 25V
C870 CCBS1H681KBT CAP , CERAMIC(680PF/50V) 680PF 50V K
C871 CCBS1H681KBT CAP , CERAMIC(680PF/50V) 680PF 50V K
C872 CCEA1CH331T CAP , ELECT 330UF 16V
C873 CCEA1CH331T CAP , ELECT 330UF 16V
C874 CCBS1H101KBT CAP , CERAMIC(100PF/50V) 100PF 50V K
C882 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C888 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C889 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C891 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V Z
C892 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V Z
C893 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V Z
C894 CCEA1CKS100T CAP , ELECT 10UF 16V
C896 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C897 CCEA1AH471T CAP , ELECT 470UF 10V
C903 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V SMALL SIZE
C905 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V SMALL SIZE
D455 CVD1SS133MT DIODE 1SS133
D774 CVD1SS133MT DIODE 1SS133
D775 CVD1SS133MT DIODE 1SS133
D784 CVD1SS133MT DIODE 1SS133
D785 CVD1SS133MT DIODE 1SS133
L702 HLQ02C100KT COIL , AXAIL 10uH
Q451 HVTKRC107MT T.R KRC107M
Q452 HVTKRA107MT T.R KRA107M
Q454 HVTKRC107MT T.R KRC107M
Q701 HVTKRC107MT T.R KRC107M
harman/kardon
AVR 355/230 Service Manual
Page 11 of 125
