Harman Kardon AVR 355 Service Manual

MAIN PCB ASSY
Ref. # Part Number Description Value
D976 CVD1SS133MT DIODE 1SS133
D979 CVDZJ5.1BT DIODE , ZENER ZJ5.1B 1/2W
ET90 HJT1A025 PALTE , EARTH MET37-0002
ET91 HJT1A025 PALTE , EARTH MET37-0002
F901 KJCFC5S HOLDER , FUSE HOLDER
F902 KBA2D2500TLET FUSE(SR-5,2.5A,250V) SAVE FUSETECH
IC97 HVIRE5VT28CATZ I.C , RESET RESET
Q501 HVTKTA1268GRT T.R KTA1268GR
Q502 HVTKTA1268GRT T.R KTA1268GR
Q503 HVTKTA1268GRT T.R KTA1268GR
Q504 HVTKTA1268GRT T.R KTA1268GR
Q505 HVTKTA1268GRT T.R KTA1268GR
Q511 HVTKTC3200GRT T.R KTC3200GR
Q512 HVTKTC3200GRT T.R KTC3200GR
Q513 HVTKTC3200GRT T.R KTC3200GR
Q514 HVTKTC3200GRT T.R KTC3200GR
Q515 HVTKTC3200GRT T.R KTC3200GR
Q516 HVTKTC3200GRT T.R KTC3200GR
Q517 HVTKTC3200GRT T.R KTC3200GR
Q518 HVTKTC3200GRT T.R KTC3200GR
Q519 HVTKTC3200GRT T.R KTC3200GR
Q520 HVTKTC3200GRT T.R KTC3200GR
Q541 HVTKTC3198YT T.R KTC3198Y
Q542 HVTKTC3198YT T.R KTC3198Y
Q543 HVTKTC3198YT T.R KTC3198Y
Q544 HVTKTC3198YT T.R KTC3198Y
Q545 HVTKTC3198YT T.R KTC3198Y
Q556 HVTKTC3200GRT T.R KTC3200GR
Q557 HVTKTC3200GRT T.R KTC3200GR
Q558 HVTKTC3200GRT T.R KTC3200GR
Q559 HVTKTC3200GRT T.R KTC3200GR
Q560 HVTKTC3200GRT T.R KTC3200GR
Q561 HVTKTC3200GRT T.R KTC3200GR
Q562 HVTKTC3200GRT T.R KTC3200GR
Q563 HVTKTC3200GRT T.R KTC3200GR
Q564 HVTKTC3200GRT T.R KTC3200GR
Q565 HVTKTC3200GRT T.R KTC3200GR
Q601 HVTKTA1268GRT T.R KTA1268GR
Q602 HVTKTA1268GRT T.R KTA1268GR
Q603 HVTKTA1268GRT T.R KTA1268GR
Q604 HVTKTA1268GRT T.R KTA1268GR
Q605 HVTKTA1268GRT T.R KTA1268GR
Q681 HVTKSC2785YT T.R KSC2785Y
Q682 HVTKSC2785YT T.R KSC2785Y
Q683 HVTKSC2785YT T.R KSC2785Y
Q684 HVTKSC2785YT T.R KSC2785Y
Q685 HVTKSC2785YT T.R KSC2785Y
Q801 HVTKSC2785YT T.R KSC2785Y
Q802 HVTKSC2785YT T.R KSC2785Y
Q812 HVTKTA1268GRT T.R KTA1268GR
Q813 HVTKTC3200GRT T.R KTC3200GR
Q814 HVTKTA1268GRT T.R KTA1268GR
Q815 HVTKTC3200GRT T.R KTC3200GR
Q816 HVTKTA1268GRT T.R KTA1268GR
Q817 HVTKTA1268GRT T.R KTA1268GR
Q818 HVTKTC3200GRT T.R KTC3200GR
Q819 HVTKTC3200GRT T.R KTC3200GR
Q820 HVTKTC3200GRT T.R KTC3200GR
Q821 HVTKTC3200GRT T.R KTC3200GR
Q822 HVTKTC3200GRT T.R KTC3200GR
harman/kardon
AVR 355/230 Service Manual
Page 17 of 125
