Harman Kardon AVR 355 Service Manual

MAIN PCB ASSY
Ref. # Part Number Description Value
Q823 HVTKTC3200GRT T.R KTC3200GR
Q824 HVTKTC3198YT T.R KTC3198Y
Q825 HVTKTC3198YT T.R KTC3198Y
Q901 HVTKSC2785YT T.R KSC2785Y
Q911 HVTKTA1271YT T.R KTA1271Y
Q912 HVTKTA1271YT T.R KTA1271Y
Q913 HVTKTA1271YT T.R KTA1271Y
Q914 HVTKTA1271YT T.R KTA1271Y
Q915 HVTKSC2785YT T.R KSC2785Y
Q916 HVTKSC2785YT T.R KSC2785Y
Q917 HVTKSC2785YT T.R KSC2785Y
Q918 HVTKSC2785YT T.R KSC2785Y
Q938 HVTKRA107MT T.R KRA107M
Q939 HVTKRA107MT T.R KRA107M
Q941 HVTKSC2785YT T.R KSC2785Y
Q942 HVTKSC2785YT T.R KSC2785Y
Q943 HVTKSC2785YT T.R KSC2785Y
Q951 HVTKRC107MT T.R KRC107M
Q952 HVTKRA107MT T.R KRA107M
Q960 HVTKRC107MT T.R KRC107M
Q961 HVTKTA1024YT T.R A1024Y
Q991 HVTKRC107MT T.R KRC107M
Q992 HVTKRA107MT T.R KRA107M
Q993 HVTKRA107MT T.R KRA107M
Q994 HVTKRC107MT T.R KRC107M
Q997 HVTKRA107MT T.R KRA107M
Q998 HVTKRC107MT T.R KRC107M
R501 CRD20TJ433T RES , CARBON 43K OHM 1/5W J
R502 CRD20TJ433T RES , CARBON 43K OHM 1/5W J
R503 CRD20TJ433T RES , CARBON 43K OHM 1/5W J
R504 CRD20TJ433T RES , CARBON 43K OHM 1/5W J
R505 CRD20TJ433T RES , CARBON 43K OHM 1/5W J
R506 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R507 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R508 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R509 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R510 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R511 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R512 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R513 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R514 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R515 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R516 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R517 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R518 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R519 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R520 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R521 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R522 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R523 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R524 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R525 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R531 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R532 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R533 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R534 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R535 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R536 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R537 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R538 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
harman/kardon
AVR 355/230 Service Manual
Page 18 of 125
