Harman Kardon AVR 3600 Service Manual

SiI9135/9135A HDMI Receiver with Enhanced Audio and Deep Color Outputs
Data Sheet
Silicon Image, Inc.
Pin Diagram
Figure 2 shows the pin connections for the SiI9135 receiver in the 144-pin TQFP package. Packaging and pin
assignments are identical for the SiI9135A device.
Figure 2. Pin Diagram
Individual pin functions are described beginning on page 32.
AVR3600 harman/kardon
110

Harman Kardon AVR 3600 Specifications

General

Brand	Harman Kardon
Model	AVR 3600
Category	Receiver
Language	English
