Harman Kardon AVR 3600 Service Manual

Ref. Designator Part Number Qty
Description
FRONT PCB ASS'Y COP12168D
C912 CCEA1EH470T CAP , ELECT 47UF 25V 1 EA
C923 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
C924 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
C931 CCEA1CH331T CAP , ELECT 330UF 16V 1 EA
C932 CCEA1CH331T CAP , ELECT 330UF 16V 1 EA
C411 CCEA1JH101E CAP , ELECT 100UF 63V 1 EA
Semiconductors
D161 HVD1N5819T DIODE , SCHOTTKY 1N5819 1 EA
D401 CVD1N4003ST DIODE , RECT 1N4003 1 EA
D412 HVDMTZJ6.8BT DIODE , ZENER MTZJ6.8B 1/2W 1 EA
D413 HVDMTZJ27BT DIODE , ZENER MTZJ27B 1/2W 1 EA
D421 HVDMTZJ6.8BT DIODE , ZENER MTZJ6.8B 1/2W 1 EA
D422 HVDMTZJ6.8BT DIODE , ZENER MTZJ6.8B 1/2W 1 EA
D455 CVD1SS133MT DIODE 1SS133 1 EA
D531 CVD1SS133MT DIODE 1SS133 1 EA
D534 CVD1SS133MT DIODE 1SS133 1 EA
D631 CVD1SS133MT DIODE 1SS133 1 EA
D632 CVD1SS133MT DIODE 1SS133 1 EA
D633 CVD1SS133MT DIODE 1SS133 1 EA
D634 CVD1SS133MT DIODE 1SS133 1 EA
D714 C3A206 WIRE , COPPER SN95/PB5 , 0.6 0.02 M
Q104 CVTKTC1027YT
TRANSISTOR NPN
KTC1027Y 1 EA
Q111 HVTKRA107MT
TRANSISTOR PNP
KRA107M 1 EA
Q112 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
Q113 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
Q251 HVTKTA1271YT
TRANSISTOR PNP
KTA1271Y 1 EA
Q252 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
Q721 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
Q941 HVTKTC2874BT
TRANSISTOR , MUTE NPN
KTC2874B 1 EA
Q942 HVTKTC2874BT
TRANSISTOR , MUTE NPN
KTC2874B 1 EA
Q943 HVTKTC2874BT
TRANSISTOR , MUTE NPN
KTC2874B 1 EA
Q944 HVTKTC2874BT
TRANSISTOR , MUTE NPN
KTC2874B 1 EA
Q951 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
Q952 HVTKRA107MT
TRANSISTOR PNP
KRA107M 1 EA
Q954 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
D101 CVD1L0345W31BOCT201V L.E.D , WHITE CVD1L0345W31BOCT201 1 EA
D102 CVD30ASOGCAA-S7 L.E.D , ORANGE T0L-30ASOGCAA-S7 1 EA
D201 CVD1L0345W31BOCT201V L.E.D , WHITE CVD1L0345W31BOCT201 1 EA
D202 CVD1L0345W31BOCT201V L.E.D , WHITE CVD1L0345W31BOCT201 1 EA
D203 CVD1L0345W31BOCT201V L.E.D , WHITE CVD1L0345W31BOCT201 1 EA
IC11 HVI74HCU04AFNG I.C , INVERTER (TOSHIBA) TC74HCU04AFNG(TOSHIBA) 1 EA
IC12 HRVNJL34H380A SENSOR , REMOCON (JRC) NJL34H380A(PB-F 1 EA
IC13 HVI74ACT04MTR I.C , HEX (ST) INVERTER 74ACT04MTR 1 EA
IC14 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC15 HVINJM4556AL I.C , HEADPHONE (JRC) DUAL OP AMP NJM4556AL 1 EA
Resistors
R101 CRD20TF2200T RES , CARBON(220 OHM, 1%) 220 OHM, 1% 1 EA
R102 CRD20TF6800T RES , CARBON(680 OHM, 1%) 680 OHM, 1% 1 EA
R113 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R121 CRD20TJ473T RES , CARBON 47K OHM 1/5W J 1 EA
R122 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1 EA
R201 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1 EA
R202 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1 EA
R203 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1 EA
R211 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1 EA
R213 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J 1 EA
R214 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J 1 EA
R251 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J 1 EA
R252 CRD25TJ393T RES , CARBON (39K OHM) 39K OHM 1 EA
R312 CRD20TF1001T RES , CARBON 1K /1/5W /F 1 EA
AVR3600 harman/kardon
41
