060116EBP
TMP86F409NG
CMOS 8-Bit Microcontroller
This product uses the Super Flash technology under the licence of Silicon Storage Technology, Inc. Super Flash is registered trademark of Silicon
Storage Technology, Inc.
TMP86F409NG
1.1 Features
1. 8-bit single chip microcomputer TLCS-870/C series
- Instruction execution time :
0.25 µs (at 16 MHz)
122 µs (at 32.768 kHz)
- 132 types & 731 basic instructions
2. 17interrupt sources (External : 5 Internal : 12)
3. Input / Output ports (26 pins)
Large current output: 8pins (Typ. 20mA), LED direct drive
4. Prescaler
- Time base timer
- Divider output function
5. Watchdog Timer
6. 16-bit timer counter: 1 ch
- Timer, External trigger, Window, Pulse width measurement,
Event counter, Programmable pulse generate (PPG) modes
7. 8-bit timer counter : 2 ch
- Timer, Event counter, Programmable divider output (PDO),
Pulse width modulation (PWM) output,
Programmable pulse generation (PPG) modes
8. 8-bit UART : 1 ch
Product No.
ROM
(FLASH)
RAM Package Emulation Chip
TMP86F409NG
4096
bytes
512
bytes
SDIP32-P-400-1.78 TMP86C909/987XB
