Harman Kardon AVR 505 User Manual

2/2
Pos Part number 1st part name 2nd part name
CB13 CWC1C4A13B080B CABLE , CARD 13pins FFC TUNER - DSP
CB15 CWC1C4A09B100B CABLE , CARD 9pins FFC VIDEO DSP
CHE170 HOLDER , PCB
CHG1A104 CUSHION , EVA H=9.5(15X20)
CHG1A157 CUSHION , RUBBER
CJA2B043ZA CORD , POWER(EUR) QDR-7100CC
CKF4A254Y PANEL , REAR AVR505
CKL1A069H43 FOOT
CLZ9W003Z FERRITE , RING 29X7.7X19
CMD1A487 BRACKET , TRANS
CNVKSTM9014MS17 TUNER MODULE(EUR)
CTB3+10G SCREW
CTB3+16GFZ SCREW
CTWS3+10G SCREW
KBC1A147MBZC22 KNOB , MOMS
KBT1A903MMZC22 KNOB , POWER
KBT1A904MBZC22 KNOB , SET
KBT1A905MBYC22 KNOB , FUNCTION
KHR301 CLAMPER
BN72 CWZAVR230BN72 WIRE ASS'Y
CKC1B145S46 CABINET , TOP
CLZ9Z028Z FERRITE CORE(21.2X6.4X12.7)
CMH1A214 HOLDER , VOLUME
CMZ1A090 SHEET , VOLUME
CTB3+8JFC SCREW
CTB4+6FFC SCREW
1/10
Pos Part number 1st part name 2nd part name
COP11578E FRONT PCB ASS'Y
C712 HCEA1HH1R0T CAP , ELECT 1UF 50V
C713 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C714 HCBS1H151KBT CAP , CERAMIC 150PF 50V K
C716 HCEA1CH331T CAP , ELECT
C717 HCBS1H221KBT CAP , CERAMIC 220PF 50V K
C718 HCBS1H221KBT CAP , CERAMIC 220PF 50V K
C719 HCBS1H181KBT CAP , CERAMIC 180PF 50V K
C720 HCBS1H181KBT CAP , CERAMIC 180PF 50V K
C721 HCBS1H181KBT CAP , CERAMIC 180PF 50V K
C722 HCEA1CH101T CAP , ELECT 100UF 16V
C723 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C724 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C725 CCKT1H473ZF CAP , CERAMIC 0.047UF 50V ZF
C726 HCEA0JH102T CAP , ELECT 1000UF 6.3V
AVR130 MECH
AVR130 FRONT BD

Harman Kardon AVR 505 Specifications

General

Brand	Harman Kardon
Model	AVR 505
Category	Receiver
Language	English
