Harman Kardon AVR 505 User Manual

2/10
Pos Part number 1st part name 2nd part name
C727 HCBS1H221KBT CAP , CERAMIC 220PF 50V K
C728 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C729 CCKT1H473ZF CAP , CERAMIC 0.047UF 50V ZF
C730 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C731 HCEA1HH100T CAP , ELECT 10UF 50V
C732 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C733 HCEA1EH470T CAP , ELECT 47UF 25V
C735 HCEA1VH100T CAP , ELECT 10UF 35V
C736 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C737 HCBS1H180JT CAP , CERAMIC
C738 HCBS1H180JT CAP , CERAMIC
C770 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C771 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C773 HCEA1VH100T CAP , ELECT 10UF 35V
C774 HCEA1VH100T CAP , ELECT 10UF 35V
C775 HCBS1H151KBT CAP , CERAMIC 150PF 50V K
C776 HCBS1H151KBT CAP , CERAMIC 150PF 50V K
C777 HCEA1VH100T CAP , ELECT 10UF 35V
C778 HCEA1VH100T CAP , ELECT 10UF 35V
C779 HCEA1CKS470T CAP, ELECT
C780 HCEA1CKS470T CAP, ELECT
C781 HCEA1CKS100T CAP , ELECT
C782 HCEA1CKS100T CAP , ELECT
C785 HCBS1H470JT CAP , CERAMIC 47PF 50V J
C786 HCBS1H470JT CAP , CERAMIC 47PF 50V J
C787 HCEA1CKS100T CAP , ELECT
C788 HCEA1CKS100T CAP , ELECT
C789 HCEA1CKS100T CAP , ELECT
C790 HCEA1CKS100T CAP , ELECT
C791 HCEA1CKS470T CAP, ELECT
C792 HCEA1CKS470T CAP, ELECT
C793 KCFE1J183JBT CAP , FILM 0.018UF 63V J
C794 KCFE1J183JBT CAP , FILM 0.018UF 63V J
C795 KCFE1J823JBT CAP , FILM 0.082UF 63V J
C796 KCFE1J823JBT CAP , FILM 0.082UF 63V J
C797 KCFE1J332JBT CAP , FILM 0.0033UF 63V J
C798 KCFE1J332JBT CAP , FILM 0.0033UF 63V J
C799 KCFE1J183JBT CAP , FILM 0.018UF 63V J
C800 KCFE1J183JBT CAP , FILM 0.018UF 63V J
C805 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C806 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C807 CCKT1H104ZF CAP , CERAMIC 50V 0.1UF
C808 CCKT1H181KB CAP , CERAMIC 180PF 50V KB
C809 HCEA1AH471T CAP , ELECT 470UF 10V
AVR130 FRONT BD
