Model FL 8385

Description 5-Disc CD changer

Plays CD-R Yes

Plays CD-RW Yes

HDCD

Yes

Audio Output DACs 18-Bit Burr-Brown

™

Programmed Play 20 Tracks

Repeat Play 1 Track, 1 CD, all CDs

Digital Output Coax

Headphone Jack

Yes

With Level Control

Remote Yes

Separate Remote

Yes

On/Off Buttons

IR-In/Out Jacks Yes

Dimensions (H x W x D) 5-1/8" x 17-5/16" x 15-1/4"

Weight 18 lb

Model CP 65 CP 60 CP55

Channel Configuration 5.1-Channel system 5.1-Channel system 5.1-Channel system

Audio/Video Receiver AVR 347 AVR 247 AVR 146

DVD Player DVD 48 DVD 38 DVD 38

Loudspeaker Complement HKTS 18 (black-lacquer finish) HKTS 15 (black-lacquer finish) HKTS 15 (black-lacquer finish)

Accessories Included RCP 7 universal remote control, RCP 6 universal remote control, RCP 5 universal remote control

color-coded cable labels, color-coded cable labels, with EzSet,

EzSet/EQ

™

microphone, EzSet/EQ

™

microphone, color-coded cable labels,

all necessary cables all necessary cables all necessary cables

Model ABH 4000 ABH 4 AB 2 AB 1

Description Four-zone/eight-room Four-room A-BUS

A-BUS

in-wall module with Multisource A-BUS

in-wall

A-BUS

expansion hub expansion hub onboard controls and built-in amplifier module with built-in amplifier

System Requirements AB 2, AB 1 or other AB 2, AB 1 or other Harman Kardon

Harman Kardon

A-BUS-compatible modules; A-BUS-compatible modules; A-BUS Ready receiver, A-BUS Ready receiver,

connects to any analog input connects to any analog input ABH Series expansion hub ABH Series expansion hub

source; Harman Kardon

or compatible or compatible

A-BUS Ready receiver A-BUS Ready receiver A-BUS products A-BUS products

System Connection Cat. 5/5e cable or better Cat. 5/5e cable or better System: Cat. 5/5e or better System: Cat. 5/5e or better

Speakers: Up to 14 AWG Speakers: Up to 14 AWG

Dimensions ABH: 4.2" x 9.5" x 1.5" ABH: 3.4" x 7.2" x 1.2" 4.3 x 1.8" x 1.3" 4.3 x 1.8" x 2.3"

(H x W x D) Power Supply: 2.8: x 6.0" x 1.5" Power Supply: 1.5" x 5.9" x 2.8"

Weight ABH: 1.0 lb; Power Supply: 1.0 lb ABH: 0.9 lb; Power Supply: 1.0 lb .25 lb .25 lb

Model EP 730 EP 720 EP 710

Description Noise-isolating earphones Noise-isolating earphones Noise-isolating earphones

Plug Type 1/8" Stereo, 1/8" Stereo, 1/8" Stereo,

compatible with iPod and compatible with iPod and compatible with iPod and

most portable players most portable players most portable players

Bass Reproduction High-Fidelity and Enhanced bass Enhanced bass

Bass Boost modes reproduction, even at reproduction, even at

with in-line switch low listening levels low listening levels

In-Line Volume Control Yes No No

Carrying Case Yes Yes Yes

Foam Inserts Yes Yes Yes

Transducer Type Balanced armature Balanced armature Moving coil

Frequency Response 20Hz – 15kHz (±6dB) 20Hz – 15kHz (±7dB) 20Hz – 16kHz (±8dB)

Sensitivity 95dB SPL (max VC) 105dB SPL 96dB SPL

(@ 1kHz, in High-Fidelity mode;

0.1Vrms Input) 105dB SPL (fixed)

in Bass Boost mode

Nominal Accuracy 90% (High-Fidelity mode); 81% 82%

Score 81% (Bass Boost mode)

Impedance 48 Ohms (High-Fidelity mode); 16 Ohms (nominal) 16 Ohms (nominal)

16 ohms (Bass Boost mode)

Maximum Output 120dB SPL 120dB SPL 120dB SPL

Natural Noise Isolation 35dB with 3-flange ear tips, 35dB with 3-flange 30dB with 3-flange

40dB with foam ear tips ear tips ear tips

Dimensions (Cord Length) 6 ft 6 ft 6 ft

Weight 2 oz 2 oz 2 oz

Available in Black or White

44 45

Model DVD 48 DVD 38

Description Progressive-scan DVD audio/video and SACD

™

player with HDMI

™

Progressive-scan DVD audio/video player with HDMI

™

Video Formats DVD, DVD-R/RW, DVD+R/RW, VCD DVD, DVD-R/RW, DVD+R/RW, VCD

Audio Formats DVD-Audio, SACD, CD, CD-R/RW, MP3, WMA** DVD-Audio, CD, CD-R/RW, MP3, WMA**

HDMI

™

Output Yes, HDMI 1.1 Yes, HDMI 1.0

Simplay HD

™

-Verified Yes Yes

Still-Image Formats JPEG, Kodak

Picture CD JPEG, Kodak

Picture CD

Audio DACs 192kHz/24-bit 192kHz/24-bit

Video DACs 27MHz – 54MHz/10-bit; 216MHz/12-bit in HD mode 27MHz – 54MHz/10-bit

Video Outputs 480i, 480p, 720p, 1080i, 1080p 480i, 480p, 720p, 1080i

Video Test Screen No Yes

Video-Off Mode Yes Yes

Screen Saver Yes Yes

Compressed-Audio Bit Rates MP3: 32 kbps – 320 kbps; WMA: 64 kbps – 320 kbps MP3: 32 kbps – 320 kbps; WMA: 64 kbps – 320 kbps

JPEG Resolution 5 Megapixels, 5MB file size 5 Megapixels, 5MB file size

Disc-Recognition Memory No DVD-Video/MP3/WMA: 5 discs

Still-Image Rotation 90° increments 90° increments

Slow Play Forward 1/2x, 1/4x, 1/8x, 1/16x 1/2x, 1/4x, 1/8x, 1/16x

Slow Play Reverse 1/2x, 1/4x 1/2x, 1/4x

Fast Play 1-1/2x, 4x, 6x, 8x,16x, 32x 2x, 4x, 8x, 20x,100x

Random Play CDs only CDs only

Repeat Play Disc, track, A/B

†

Disc, track, A/B

†

Programmed Play CDs only CDs only

Digital-Audio Outputs Coax, optical, HDMI 1.1 Coax, optical, HDMI 1.0

Remote Backlit Backlit

IR-In/Out Jacks Yes Yes

Dimensions (H x W x D) 2" x 17-5/16" x 11-1/4" 2" x 17-5/16" x 11-1/4"

Weight 6 lb 6 lb

** Windows Media

Audio (WMA) is a proprietary file format developed by Microsoft.

†

A/B Repeat Play is available for DVDs, CDs and VCDs only (SACD discs on DVD 48 only).

Model HS 300

Description 5.1-Channel integrated home theater system

Multichannel Power 35W x 5,* THD <0.07%, 20Hz – 20kHz into 8 ohms

Speaker System HKTS 11

Surround Formats DTS,

Dolby

Digital, Dolby Pro Logic

DVD Player Progressive scan

External Audio Connection Tape-in/out, TV-in

Digital-Audio Inputs (Coax/Optical) 1/1

USB Input (Side/Rear) 1/1

Video Outputs HDMI,

™

composite, S, component

Video Formats DVD, DVD-R/RW, DVD+R/RW, VCD, SVCD

Audio Formats DVD-Audio, CD, CD-R/RW, MP3, WMA**

Compressed-Audio Bit Rates MP3: 32kbps – 320kbps; WMA: 16kbps – 192kbps

Still-Image Formats JPEG, Kodak

Picture CD

JPEG Resolution 5 Megapixels, 5MB file size

Still-Image Rotation 90° Increments

Upscaling 720p and 1080i

Tuner AM/FM, 30 presets

Test Screen Yes

Fast Play 2x, 4x, 16x, 100x

Slow Play 1/2x, 1/4x, 1/8x, 1/16x

Random and Programmed Play Yes, CD only

Repeat Play 1 Track, 1 CD, A/B

†

Remote System remote

Dimensions (H x W x D) 2-11/16" x 17-5/16" x 15"

Weight (Excluding Speaker System) 10.6 lb

** Windows Media

Audio (WMA) is a proprietary file format developed by Microsoft.

†

A/B Repeat Play is available for DVDs, CDs and VCDs only.

Model HTFS 2

††

Aluminum-Extrusion Column Yes

Wire-Management System Yes

Height, Assembled, Not Including Floor Spikes and Without Speaker 34-1/2"

Base 9" x 7" Oval

Weight 16.7 lb

††

Some assembly required. Available in silver or black-lacquer finish.

NOTE: Depth measurements include knobs, buttons and terminal connections; height measurements include feet and chassis. All features and

specifications are subject to change without notice.

Harman Kardon, EzSet, (patent no. 5,386,478), EzSet+, , Lexicon, Logic 7 and SoundSticks are trademarks of

Harman International Industries, Incorporated, registered in the United States and/or other countries. Designed to Entertain, , EzSet EQ,

and Drive + Play are trademarks of Harman International Industries, Incorporated. A-BUS is a registered trademark of LeisureTech

Electronics Pty Ltd. Burr-Brown is a trademark of Texas Instruments. Cirrus and Cirrus Logic are registered trademarks of Cirrus Logic, Inc. DCDi by

Faroudja is a registered trademark of Genesis Microchip Inc. Dolby and Pro Logic are registered trademarks of Dolby Laboratories. DTS, DTS-ES and

DTS Neo:6 are registered trademarks, and DTS 96/24 is a trademark, of DTS, Inc. HDCD (High Definition Compatible Digital), Microsoft, Windows

and Windows Media are registered trademarks of Microsoft Corporation in the United States and/or other countries. HDMI (High-Definition Multimedia

Interface) is a trademark of HDMI Licensing LLC. iPod and Mac OS are trademarks of Apple Inc., registered in the U.S. and other countries. Shuffle is

a trademark of Apple Inc. Kodak is a registered trademark of Eastman Kodak Company. SACD is a trademark of Sony Corporation. The Simplay HD

logo and the Simplay, Simplay HD and Simplay Labs trademarks are owned by Silicon Image, Inc., and are used under license from Silicon Image, Inc.,

and/or Simplay Labs, LLC. ThumbDrive is a trademark of Trek 2000 International Limited.

Model HKTS 18 HKTS 15 HKS 9 HKS 6

Satellites 4 Identical 2-way satellites with dual 3" midranges 4 Identical 2-way satellites with 3" midrange 2 Identical 2-way satellites with dual 3" midranges 2 Identical 2-way satellites with 3" midrange

3/4"-dome tweeter, video-shielded and 1/2"-dome tweeter, video-shielded and 3/4"-dome tweeter, video-shielded and 1/2"-dome tweeter, video-shielded

Center Channel Speaker Voice-matched with dual 3" midranges Voice-matched with dual 3" midranges N/A N/A

and 3/4"-dome tweeter, video-shielded and 3/4"-dome tweeter, video-shielded

Subwoofer 200-Watt, bass-reflex powered 100-Watt, bass-reflex powered

N/A N/A

subwoofer with 10" driver; external trigger input subwoofer with 10" driver; external trigger input

Nominal Impedance 8 Ohms (sats & center) 8 Ohms (sats & center) 8 Ohms 8 Ohms

Sensitivity (SPL @ 1 Watt/Meter) 86dB (sats & center) 86dB (sats & center) 86dB 86dB

Frequency Response System: 25Hz – 20kHz (–6dB) System: 35Hz – 20kHz (–6dB) 105Hz – 20kHz (–6dB) 110Hz – 20kHz (–6dB)

Line-Level Inputs Stereo RCA jacks and dedicated LFE Stereo RCA jacks and dedicated LFE N/A N/A

Speaker-Level Inputs & Outputs Binding posts (sub); spring lever inputs (sats & center) Binding posts (sub); spring lever inputs (sats & center) Spring lever (inputs only) Spring lever (inputs only)

Recommended Amplifier Power 10W – 120W 10W – 80W 10W – 120W 10W – 80W

Subwoofer Level Control Yes Yes N/A N/A

Phase Switch Yes Yes N/A N/A

Audio Sense Turn-On Yes Yes N/A N/A

Low-Pass Filter Switch Yes Yes N/A N/A

Cables Included Yes Yes Yes Yes

Wall-Mount Capability Brackets included for center and satellites Brackets included for center and satellites Pair of brackets included Pair of brackets included

Dimensions (H x W x D) Sats: 9-9/16" x 3-15/16" x 3-5/8" Sats: 6-9/16" x 3-15/16" x 3-5/8" 9-9/16" x 3-15/16" x 3-5/8" 6-9/16" x 3-15/16" x 3-5/8"

Center: 4" x 9-1/2" x 3-5/8" Center: 4" x 9-1/2" x 3-5/8"

Sub: 18-7/8" x 13-3/8" x 13-3/8" Sub: 18-7/8" x 13-3/8" x 13-3/8"
