FM Antenna
AM Antenna
Video 1 A/V Inputs
Video 1 A/V Outputs
Video 2 A/V Inputs
Video Monitor Output
Video 3 A/V Inputs
Remote IR Input
Remote IR Output
AC Power Cord
Preamp Outputs
Subwoofer Outputs
Main-Amp Inputs
Speaker 2 Outputs
Switched AC Accessory Outlets
Speaker 1 Outputs
Phono Inputs and Ground
CD Inputs
Tape Inputs
Tape Outputs
NOTE: To make it easier to follow the instructions throughout the manual that refer to this illustration, a copy of this page may be downloaded from the Product Support section at
www.harmankardon.com.
