Harman Kardon ONYX Black spare parts list
Spare parts (the
Location refer to
1 01 27 1 ASSY-MAIN BOARD 08-KS321U-MA0
2 002 D2,D8,D9 3 DIODE SS24A DO-214AC 09-0SS24A-STX
3 002 D4 1 DIODE BAT54C SOT-23 09-BAT54C-STXGA
4 002 D1,D11,D12 3 DIODE B5819W SOD-123 09-BRX140-STXGA
5 002 D402,D5 2 SMD SWITCHING DIODE LL4148 LL-34 09-LL4148-ATX
6 002 Q10,Q2,Q24,Q3,Q6 5 P-CHANNEL ENHANCEMENT MOSFET AP2305A 12-AP2305-0BX
7 002 Q4,Q5 2 N-CHANNEL AP2316GH-HF SOT-23 12-AP2316-0BX
8 002 Q26 1 N-CHANNEL MOSFET AP9476 SO-8 12-AP9476-0BX
9 002 Q12,Q18,Q21,Q25,Q7,Q8 6 NPN TRANSISTOR 3DG3904M SOT-23 12-BT3904-0BX
10 002 Q555 1 N-CHANNEL MOSFET 2SK3018 SOT-323 12-SK3018-0BX
11 002 Q17,Q19 2 NPN TRANSISTOR TC1815 SMD SOT-23 12-TC1815-GBX
12 002 U13 1 ADC DAC IC AK7742EQ 13-AK7742-EQB
13 002 U3 1 IC AS1117 13-AS1117-ADB
14 002 U1 1 IC BQ24617RGER RGE QFN24 LI-POLYMER BAT 13-BQ2461-7RG3
15 002 U23 1 IC BU26507GUL MATRIX LED DRIVER 13-BU2650-7GU3
16 002 U5 1 IC EUP3482ADIR1 13-EUP348-2ADI3
17 002 U6 1 IC EUP3484SDIR1 SOP-8(EP) DC-DC 13-EUP348-4SD3
18 002 U4 1 IC GMT5725 GMT 1A DC/DC 13-G5725A-T11U
19 002 U2 1 IC LM3478MM DC-DC 13-LM3478-MM03
20 002 U12 1 IC NX3DV42GU 13-NX3DV4-2GU3
21 002 U19 1 IC SWITCH SN74CB 13-SN74CB-TLV
22 002 U14 1
IC MCU（STM32F105RC）
13-STM32F-1050
23
002
U16,U17 2 IC TPA3116D2 AMP 13-TPA311-6D22
24 002 U11,U15 2 IC CP2.0C 13-US08N0-00B
25 002 Y1 1 CRYSTAL 12.288MHz 45-OSC12M-2NABY-M
26 002 Y2 1 CRYSTAL 14.7456MHZ 45-OSC14M-7N0CT-M
27 01 10 1 ASSY-IN BOARD 08-KS321U-CNY
28 002 ESD1,ESD2 2 IC ESD PROTECTION IC LVSL10180Z020 13-10180Z-02T
29 002 P2 1 MIC JACK 3.5MM 47-MIC011-XX0
30 002 P3 1 DC POWER JACK,D6.5MM/D2.0MM,30V/3.5A 47-PWS046-XX0
31 002 P1 1 USB SOCKET MODEL A 47-USB012-XX0
32 002 SW4,SW5 2 TACT SWITCH 6*6*5 48-TAC020-XX2
33 01 25+26 1 ASSY-TOUCH BOARD & KEY BRACKET 08-KS321U-TH0
34 01 NFC BOARD 1 ASSY-NFC BOARD 08-KS321U-NFY
35 01 AIRPLAY 1 AIRPLAY MODULE 07-APM870-3IB
36 01 30+31 1 ASSY-FRONT FAKE SPEAKER 08-NESME4-001
37 002 30 1 FRONT FAKE SPEAKER BRACKET 62-NESME4-0HN
38 002 31 1 FRONT FAKE SPEAKER CONE PAPER 54-NE1190-00001
39 01 22+23 1 ASSY-BACK FAKE SPEAKER 08-NESME6-001
40 002 23 1 BACK FAKE SPEAKER BRACKET 62-NESME6-0HN
41 002 22 1 BACK FAKE SPEAKER CONE PAPER 54-NE1190-00002
42 01 11 1 ASSY-BATTERY BOX COVER 08-NESME2-001
43 01 9 1 TERMINAL SEALING COVER 08-NESME3-001
44 01 12+EVA 1 ASSY-BOTTOM COVER 08-NESMR1-001
45 002 12
1
BOTTOM COVER 02-NESMR1-XX0B1
46 002 EVA 1 EVA RING 54-144400-000
47 01 16+17 1 ASSY-SKIN NET 08-ONESR2-001
48 002 17 1 SKIN NET 54-144420-000B1
49 002 16 1 SKIN NET SHELF 55-NESMR2-0HAB1
50 01 1+3+4 1 ASSY-FABRIC NETWORK SHELF 08-NESMT2-001
51 002 4 1 FABRIC NETWORK SHELF 56-NESMT2-0HN
52 002 1 1 LOGO 67-NESMC1-0A3B1
53 002 3 1 FABRIC NETWORK 54-144410-000B1
54 01 29 2 1'' TWEETER 42-011015-04001
55 01 8 2 3'' SPEAKER 42-035015-04001
56 01 7 1 TOP COVER 55-NESMT1-0UAB1
57 01 15 1 LEFT GLAND 56-NESME8-0HHB1
58 01 21 1 RIGHT GLAND 56-NESME9-0HHB1
59 01 6 1 SILICONE OUTER RING 59-NESM01-000B1
60 01 5 10 SILICONE COLUMN 59-NESM03-000B1
61 01 18+19 1 ASSY-STAINLESS STEEL HANDLE 08-NESMH1-004
62 01 24 2 CONNECTION PLATE 67-NESMQ1-0E0
63 01 28 2 STEEL SLICE 67-NESMQ2-0E0
64 01 SHEET 1 SAFETY SHEET 70-HARMHK-SAFB1
65 01 LABEL 1 GIFT BOX LABEL 71-HKSMAL-BARB2
66 01 QSG 1 QSG 72-HKSMAL-QSGB2
67 01 T EGG TRAY 1 TOP EGG TRAY
76-144430-0ATB1
68 01 B EGG TRAY 1 BOTTOM EGG TRAY 76-144440-0ATB1
69 01 GBOX 1 GIFT BOX 76-144510-0ATB2
70 01 CBOX 1 CARTON BOX 76-144520-0ATB1
71 01 ADAPTER 1 ADAPTER 81-ADT190-307GC-A
72 01 BATTERY 1 LITHIUM BATTERY 2500MA/11.1V 49-112500-BAT2-M
Part NumberNo. Level Location QTY Spec Description
Airplay module new part no: 08-AIRPLY-002
