Installation and Connections
9
Signature 1.5
BRIDGE IN
POWER AMP
TRIGGER IN
AC 12OV/60Hz 600W
4 Ω MIN.
SPEAKER
OUTPUT
IN
BRIDGE
NORMAL
1
CHANNEL ONE (RIGHT)
SPEAKER
IN
2
CHANNEL TWO (LEFT/BRIDGE)
4
Ω MIN.
( ) BRIDGE ( )
8Ω MIN
AC INPUT
-
+
Processor or Preamp
Speaker or Subwoofer
Installation for Bridged Mono
Applications
Important Note: When the Signature 1.5 is used in the Bridged Mono mode, do not use speakers with an impedance
rating of less than 8 ohms.
Sig 1.5 om (b) 9/17/98 10:33 AM Page 9
