Harman Kardon SUB-TS11 - Unit Exploded View

Item Description Part Number Qty
1 Screw, Amplifier 352-AM04020D210-E 10
2 SUB-TS11 Amplifier Not for Sale 1
3 SUB-TS11 Enclosure Not for Sale 1
4 Logo, Top 316-AG-00557-E 1
5 Logo, Bottom 316-AL-00553-E 1
6 10” Woofer 25PF12DZB-DW02-E 1
7 Screw, Woofer 352-FM04020D605-E 5
8 Foot Pad 320-RUB-00057-0BAE 4
12
SUB-TS11 (HKTS 11 Sub, HS300 system) harman/kardon
