Harman Kardon SUB-TS11 Service Manual

SUB-TS11 120v Electrical parts List
Part Number Description Qty Reference Designator
Input/Preamp PCB
Resistors
110-12472j52-e Resistor4.7K 1/2W ±5% CF 52mm (RoHS) 2 R201,R202
110-16102j26-e Resistor 1K 1/6W ±5% CF 26mm (RoHS) 6 R213,R214,R215,R254,R253,R304
110-16103j26-e Resistor 10K 1/6W ±5% CF 26mm (RoHS) 18
R209,R212,R216,R217,R218,R220,R221,R2
22,R225,R228,R229,R230,R232,R235,R240,
R248,R260,R270
110-16104j26-e Resistor 100K 1/6W ±5% CF 26mm (RoHS) 5 R231,R263,R266,R257,R300
110-16105j26-e Resistor 1M 1/6W ±5% CF 26mm (RoHS) 1 R259
110-16113j26-e Resistor 11K 1/6W ±5% 26mm (RoHS) 1 R268
110-16122j26-e Resistor 1.2K 1/6W ±5% CF 26mm (RoHS) 1 R265
110-16134j26-e Resistor 130K 1/6W ±5% CF 26mm (RoHS) 1 R233
110-16152j26-e Resistor 1.5K 1/6W ±5% CF 26mm (RoHS) 1 R302
110-16183j26-e Resistor 18K 1/6W ±5% CF 26mm (RoHS) 1 R262
110-16203j26-e Resistor 20K 1/6W ±5% CF 26mm (RoHS) 2 R237,R238
110-16223j26-e Resistor 22K 1/6W ±5% CF 26mm (RoHS) 6 R247,R255,R256,R249,R250,R261
110-16303j26-e Resistor 30K 1/6W ±5% CF 26mm (RoHS) 2 R223,R224
110-16472j26-e Resistor 4.7K 1/6W ±5% CF 26mm (RoHS) 3 R200,R207,R258
110-16473j26-e Resistor 47K 1/6W ±5% CF 26mm (RoHS) 2 R219,R264
110-16474j26-e Resistor 470K 1/6W ±5% CF 26mm (RoHS) 1 R251
110-16475j26-e Resistor 4.7M 1/6W ±5% CF 26mm (RoHS) 1 R303
110-16512j26-e Resistor 5.1K 1/6W ±5% CF 26mm (RoHS) 2 R210,R211
110-16622j26-e Resistor 6.2K 1/6W ±5% CF 26mm (RoHS) 1 R234
110-16684j26-e Resistor 680K 1/6W CF 26mm (RoHS) 1 R252
110-16912j26-e Resistor 9.1K 1/6W ±5% CF 26mm (RoHS) 2 R226,R227
110-16913j26-e Resistor 91K 1/6W ±5% CF 26mm (RoHS) 4 R203,R204,R205,R206
116-169091f26-e Resistor 9.09K 1/6W±1% MF 26mm (RoHS) 1 R301
116-201001j5vx-e metal oxide film Resistor 1K 2W ±5% standing 5mm (RoHS) 1 R267
115-h503a102-e
variable Resistor RV16AE-20B2-15K-A54-104(A50K) (RoHS) LEVEL 1 VR201
Capacitors
129-a154j633-e METALIZE CAP. 0.15U 63V ±5% MSC (RoHS) 2 C221,C222
129-a224j633-e METALIZE CAP. 0.22uF 63V ±5% MSC (RoHS) 1 C218
130-2b103k503-e DISC Capacitor 0.01u 50V ±10% (RoHS) 1 C238
130-2b221k503-e DISC Capacitor 220P 50V ±10% (RoHS) 12
C200,C204,C205,C207,C208,C210,C211,C2
12,C214,C220,C230,C237
130-3f104z503-e DISC Capacitor 0.1U 50V +80/-20% (RoHS) 8
C232,C242,C244,C245,C246,C252,C254,C2
56
132-183j503-e MYLAR Capacitor 0.018uF 50V ±5% (RoHS) 1 C223
132-223ja03-e MYLAR Capacitor 0.022uF 100V ±5% (RoHS) 1 C215
132-473j503-e MYLAR Capacitor 0.047U 50V ±5% (RoHS) 1 C224
132-563j503-e MYLAR Capacitor 0.056U 50V ±5% (RoHS) 1 C216
132-823j503-e MYLAR Capacitor 0.082U 50V ±5% (RoHS) 1 C217
135-3105m50-e Electrolytic CAP. 1U 50V ±20% (RoHS) 1 C228
135-3106m50-e Electrolytic CAP. 10uF 50V ±20% (RoHS) 12
C201,C202,C206,C213,C219,C231,C241,C2
43,C251,C253,C248,C247
135-3107m16-e Electrolytic CAP. 100uF 16V ±20% (RoHS) 1 C234
135-3226m50-e Electrolytic CAP. 22U 50V ±20% (RoHS) 1 C225
135-3475m16-e Electrolytic CAP.4.7U 16V ±20% (RoHS) 1 C233
135-3107m50-e Electrolytic CAP. 100U 50V ±20% (RoHS) 1 C301
135-3227m50-e Electrolytic CAP. 220uF 50V ±20% (RoHS) 1 C300
Semiconductors
192-027c1815gr-e Transistor 2SC1815GR TOSHIBA(RoHS) NPN 4 Q201,Q206,Q207,Q208
197-631n4148-e DIODE 500mW 75V 1N4148 Panjit (RoHS) 13
D201,D202,D203,D204,D205,D206,D207,D2
08,D214,D215,D216,D301,D302
199-65000513g-e
ZENER DIODE GDZJ5.1B 500mW 5.1V 2% ROHM 26mm 1N5231B 1 D213
20
SUB-TS11 (HKTS 11 Sub, HS300 system) harman/kardon

Harman Kardon SUB-TS11 Specifications

General

Inputs	RCA
Amplifier Power	100 Watts RMS
Woofer	10"
Dimensions	380mm x 380mm x 380mm
Driver	10" (250mm) down-firing woofer
