Harman Absolute63 User Manual

Harman® • Absolute63 Owner’s Manual_R6 • 2016 -___ • 11/1715
3-90-999000c
Caring for your Glass-
The glass used in your stove is manufactured to exact
standardstowithstandthehighheatofthere,butlikeall
glass, it must be treated with common sense and care. Never
abuse the glass by slamming the door shut or striking the
glasswithaheavyobject.Iftheglassisbrokenordamaged,
do not operate the stove until it has been replaced.
Glass - Replacement:
If the stove’s glass is cracked or broken, you must replace
it before operating your stove. Remove pieces carefully.
Replace glass only with Harman® replacement glass; do
not use substitutes.
Carefully remove damaged glass, gasket material, and glass
clips(setaside).Figure2.9.
Installtheselfadhesive1/4”gasketmaterialaroundthefront
face of the glass. Set the glass panel and gasket gently onto
thedoor. Install the glassclipsand1/4-20X1/4” screws.
Note:1/4-20X1/4”screwsonlyneedtobesnugt.Donot
overtighten.
Glass - Cleaning:
Sometimes it will be necessary to clean accumulated ash
from the glass surface; allowing this ash to remain on the
glass for long periods can result in “etching” due to the acidity
of the ash. Never clean the glass while it is hot, and do not
use abrasive substances. Wash the surface with cool water
andrinsethoroughly.Youmaywishtouseanon-abrasive
cleanerspecicallydesignedforuseonstoveglass.Inany
case, dry thoroughly before relighting your stove.
Inspect all Gaskets-
While the unit is cool, inspect all door gaskets to insure proper
seal. The gasket should be continuous without frays or tears;
having plyable gasket means having a correct seal for proper
operation. Figure 2.9.
Glass Gasket
Replace glass only
with high temperature
ceramic glass.
Inspect door gasket during
cleaning and inspection
(4)GlassClips
(4)1/4-20X1/4”
Button Head Screw
Figure 2.9
Distribution Blower-
Checking the distribution blowers yearly is a good habit to
get into. Dust, animal hair or anything else that can make
its way into that area can drastically cut down on the air
movement throughout the unit ultimately causing less of a
heatingefciency.
Oncetheunitisshutdownandcooled,unplugtheunitfrom
itspowersupply.Removetheleftandrightrearpanels.Once
removed, you will have access to the distribution blowers.
Figure 2.10.
Once access is gained to the rear of the unit, thoroughly
vacuum around the Distribution Blowers. Figure 2.10.
Remove Left & Right Rear Access Panels
Figure 2.10
Distribution Blowers
Cleaning Venting System-
Its is recommend that a certied chimney sweep perform
service and inspection to your chimney system to insure
your unit is vented safely and in accordance to local code.
