Harman Absolute63 - Unit Maintenance Procedures; Burn Pot Cleaning Steps; Monthly Cleaning Tasks

Harman® • Absolute63 Owner’s Manual_R6 • 2016 -___ • 11/1713
3-90-999000c
Figure 2.2
C. Unit Maintenance
Daily/Weekly Maintenance: It is recommend that the burn
pot be scraped whenever adding fuel; taking the opportunity
to clean the burn pot will insure proper daily operation.
Scraping the Burn Pot-
• Usingameresistantgloves,vigorouslyscrapethetop
holed surface and sides of the burn pot down to auger
tube, be sure to concentrate in the neck of the burnpot.
Figure 2.1.
• Scrape loosened material over edge of burnpot grate into
the ashpan.
• If needed, empty the ash pan while adding fuel and after
scraping the burn pot.
Figure 2.1
Monthly Maintenance: It is recommend that the unit
be shut down and unplugged from any power source for
a monthly cleaning. Monthly cleanings will insure proper
operation of your unit throughout the heating season.
• CleaningGlass-Onceunitiscold,useanon-abrasive
glass cleaner on glass and wipe clean.
• ScrapeandVacuumHeatExchanger.
Cleaning the Heat Exchanger-
CleantheheatexchangerwithscraperasshowninFigure
2.2.Brushorscrapetheinsideofthestovetoremoveyash.
Remove the ash pan and dispose of ashes in an approved
manner, according to local codes.
Cleaning the Burn Pot-
• Vigorously scrape the top holed surface and sides of the
burnpotdowntoaugertube,assuggestedintheDaily/
Weekly Maintenance Section.
• Usethesuppliedallenwrenchtoremoveanybuild-upthat
may have accumulated in the holes of the burn pot grate.
Simply push the allen wrench down through each hole
ensuringitisclearofanybuild-uppayingattentionnotto
damage the igniter element in the process. Figure 2.3.
Figure 2.3
Disconnect the power to the unit before removing
cover.
!
DANGER
Figure 2.4
Wing Thumb Screws
• Loosenthe(2)wingthumbscrewsonthelowerfrontangle
of the burn pot. Figure 2.4
Scrape these areas free of yash or
carbon buildup.
