Harman AKG C1000S - Battery Power Operation

22 C1000S
Powering
Inserting/replacing and testing the batteries
1
2
3
Figure 2: Insert batteries
1) Unscrew the wire-mesh cap (1).
2) Insert two AA batteries into the battery compartment to conform with the
polarity marks (+/-).
If the batteries are inserted incorrectly, the microphone will not work.
3) Screw the wire-mesh cap back onto the microphone.
4) Slide the on/off switch (3) up to "ON" to switch power to the microphone
on.
 The Status LED (2) will flash momentarily. If the batteries are in
good condition, the Status LED will extinguish.
 If the Status LED fails to flash, the batteries are dead. Insert new
batteries.
 If the Status LED lit constantly, the batteries will be flat within about
one hour. Replace with new batteries as soon as possible.
Battery power
