C1000S 27
Specifications
Working principle: Pre-polarised condenser microphone
Polar pattern: Cardioid, hypercardioid (with
PPC1000 mounted)
Frequency range: 50 to 20,000 Hz
Sensitivity: 6 mV/Pa (-44 dBV)
Max. SPL for 1% THD: 137 dB
Equivalent noise level (CCIR 468-3):
32 dB
Equivalent noise level: 21 dB-
Signal/noise ratio (A-weighted):
73 dB
Electrical impedance: 200 ohms
Recommended load impedance:
≥ 2000 ohms
Bass cut filter slope: Switchable to linear, 80 Hz
ttenuation: Switchable to -10 dB
Powering: 9 to 52 V phantom power to IEC 61938 or two
AA alkaline or rechargeable batteries
Current consumption: approx. 3 mA
Connector: 3-pin XLR
Finish: matte grayish blue
Dimensions: ø 33.5 x 229 mm / ø 1.32 x 9.01 in.
Net weight: 320 g
Shipping weight: 510 g
This product conforms to the standards listed in the Declaration of Conformity.
To view a copy of the Declaration of Conformity for this product, visit
http://www.akg.com or contact sales@akg.com.
7 Specifications
