SysEx Setup Dump Sample
Following is a simple example of a SysEx Setup dump. It takes you set by step through all of the operation com-
mands of a typical SysEx procedure.
<<SysEx Header>>
F0 00 01 1E 00 01
<<Procedure>>
43
<<Setup Dump Version>>
00 01 00 01
<<Setup Type and Setup Number>>
00 00 00 00
<<Setup Transmit Count...Lo Bytes, Hi Bytes>>
00 0A 00 06
<<12 Character Setup Name...dynamic>>
00 31 00 3A 00 52 00 76 00 62 00 20 00 32 00 3A 00 47 00 74 00 52 00 76
<<Null to indicate end of Character String>>
00 00
<<Misc Setup Data...too dynamic to document>>
00 07 00 00 00 06 00 00 00 03 00 06 00 03 00 32 00 08 00 03 00 00 00 00 00 02 00 04 00 00 00 00 00 02
00 08 00 00 00 00 01 7E 00 00 00 00 00 20 01 7F 00 00 00 00 00 20 00 00 00 00 00 00 00 20 00 01 00 00
00 00 00 20 00 02 00 00 00 00 00 20 00 00 00 00 00 00 00 00 00 00 00 00 00 00
<<SysEx End>>
F7
Section 6: Appendices
