Harman JBL BAR 5.1 Service Manual

BAR 5.1 SURR. SPEAKER SL1,SR1 BPH100415-0001 SURR SPK WALL MOUNT BKT BAR5.1 2
BAR 5.1 SURR. SPEAKER SL4,SR4
FSB012000-0601
SPEAKER DRIVER 20W FULL RANGE BAR5.1 2
BAR 5.1 SURR. SPEAKER SL5,SR5 ABE112784-0001 LED PCBA BAR5.1 2
BAR 5.1 SURR. SPEAKER SL6,SR6 GSP100137-0001 SURR SPK METAL GRILL BAR5.1 1
BAR 5.1 SURR. SPEAKER SL7,SR7 ABE112785-0001 JACK PCBA BAR5.1 2
BAR 5.1 SURR. SPEAKER SL10,SR10 ABN100831-0001 SURR SPK L/R BTM COVER BAR5.1 2
BAR 5.1 SURR. SPEAKER SL16,SR16 BRF100185-0001 RUBBER FOOT I SILICONE BAR5.1 4
BAR 5.1 SURR. SPEAKER SL19,SR19 BRF100186-0001 RUBBER FOOT C SILICONE BAR5.1 4
BAR 5.1 SURR. SPEAKER SL20,SR20 BPB120098-0001 SURR SPK BUTTON BAR5.1 2
BAR 5.1 SURR. SPEAKER SL22,SR22 ABE112783-0001 KEY PCBA BAR5.1 2
BAR 5.1 SURR. SPEAKER
SURR. SPK
CN8001 to Main
Unit
VWA200389-0002 WIRE 4P 150mm 1007#22 BLK 300V BAR5.1 2
BAR 5.1
CN1012 to
CN1012B
VWA120082-0001 WIRE 6P 110mm 2651#28 GRY 300V BAR5.1 1
BAR 5.1
CN1013 to
CN1013B
VWA120080-0001 WIRE 13P 280mm 2725#28&2854#30 30V BAR5.1 1
BAR 5.1
CN1014A to
CN1014B
VWA100016-0001 WIRE 6P 110mm 2651#28 GRY 300V BAR5.1 1
BAR 5.1
CN1006 to
CN3000
VWA120083-0001 WIRE 8P 70mm 2651#28 GRY 300V BAR5.1 1
BAR 5.1
CN5002 to
Subwoofer
CN902
VFLC12244-0160 WIRE 12P 160mm 1007#24 BLK 300V BAR5.1 1
BAR 5.1
CN5003 to
CN5004
VFL712244-0140 WIRE 7P 140mm 1007#24 BLK 300V BAR5.1 1
BAR 5.1
CN7001 to R
SURR. SPK
CN1003 to
CN1003B
VWA120081-0001 WIRE 4+3P 1007#22&2547#28 BLK/GRY 300V BAR5.1 1
BAR 5.1
CN7002 to L
SURR. SP
K
VWA200389-0001 WIRE 4P 720mm 1007#22 BLK 300V BAR5.1 1
BAR 5.1 CN7003 to SPK VWA200390-0001 WIRE 8P 660/610/260/370mm 2468#24 300V BAR5.1 1
BAR 5.1
CN7005 to
CN902
VWA200387-0001 WIRE 8P 340mm 1007#24 BLK 300V BAR5.1 1
BAR 5.1 CN7006 to SPK VWA200388-0001 WIRE 8P 660/610/260/370mm 2468#24 300V BAR5.1 1
BAR 5.1 CN8002 to SPK VWT903451-0120 TERM WIRE 2P 120mm 2468#24 300V BAR5.1 2
BAR 5.1
CN8005 to
CN8007
VSW322443-018R SHIELD WIRE 3P 180mm 2547#24 GRY BAR5.1 2
BAR 5.1
CN8010 to
CN8009
VWA120086-0001 WIRE 3P 100mm 2651#28 GRY 300V BAR5.1 2
BAR 5.1
CN8011 to
CN8013
VWA120085-0001 WIRE 2P 170mm 2651#28 GRY 300V BAR5.1 2
BAR 5.1
CN8015 to
CN8014
VWA120084-0001 WIRE 12P 100mm 2725#28&2854#30 30V BAR5.1 2
BAR 5.1 CN901 CCN396021-0103 CONNECTOR 3P BAR5.1 1
BAR 5.1
IC1002,IC1003,I
C1004,IC1005,
IC8014,IC8015
RCI001562-0001 IC 8P TP1562A-TR TSSOP BAR5.1 8
BAR 5.1 IC1006 AIC250080-C401 IC 8P SST25VF080B-50-4C-S2A BAR5.1 1
BAR 5.1 IC1007 RCI025032-0000 IC 8P GD25Q32CSIG SOP8 BAR5.1 1
BAR 5.1 IC1008 RCI495314-0001 IC 128P CS495314-CVZ LQFP BAR5.1 1
BAR 5.1 IC1009 RCI638165-0002 IC 54P EM638165TS-6G(63nm) BAR5.1 1
BAR 5.1 IC1010 RCI000603-0001 IC 8P BT603 SOP BAR5.1 1
BAR 5.1 IC1011 RCI042528-0002 IC 64P CS42528-CQZR LQFP BAR5.1 1
BAR 5.1 IC1012 RCI741157-0001 IC 6P 74LVC1G157GW SOT363 BAR5.1 1
BAR 5.1 IC1013 RCI024002-0010 IC 8P FM24C02C-SO-TG SOP BAR5.1 1
BAR 5.1 IC1014 AIC320446-C501 IC 100P STM32F446VET6 LQFP100 BAR5.1 1
BAR 5.1 IC1016 RCI111733-0005 IC 3P LD1117AG-33-AA3 3.3V SOT223 BAR5.1 1
BAR 5.1 IC1017 RCI002553-0001 IC 6P TPS2553DBV SOT23 BAR5.1 1
BAR 5.1 IC1018 RCI471700-0001 IC 10P SGM4717YMS/TR BAR5.1 1
BAR 5.1 IC1019 RCI621905-0001 IC 5P WB6219-M5 S0T23 BAR5.1 1
