Harman JBL BAR 5.1 Service Manual

JBL Bar 5.1 Spare Parts List V1.4
Product Name Pos. No. Part Number Description QTY
BAR 5.1 MAIN UNIT 1 ASL160001-0003 METAL GRILLE ASS'Y BAR5.1 1
BAR 5.1 MAIN UNIT 2 BRT100025-0001 KEY BUTTON BAR5.1 1
BAR 5.1 MAIN UNIT 3 ABE112601-0001 KEY PCBA BAR5.1 1
BAR 5.1 MAIN UNIT 4
FSB042000-0601
TW SPK DRIVER 20W BAR5.1 3
BAR 5.1 MAIN UNIT 5
FSB032000-0C01
MIDDLE SPK DRIVER 20W BAR5.1 6
BAR 5.1 MAIN UNIT 6 BPF106098-0001 MAIN FRONT SOURCING BAR5.1 1
BAR 5.1 MAIN UNIT 7 ABE112602-0001 CONNETOR PCBA BAR5.1 1
BAR 5.1 MAIN UNIT 10 BPB100097-0003 MAIN REAR HOUSING EU/AS/CN/BR/UK BAR5.1 1
BAR 5.1 MAIN UNIT 10 BPB100097-0001 MAIN REAR HOUSING US BAR5.1 1
BAR 5.1 MAIN UNIT 12 ABN112550-0001 POWER PCBA EU/AS/CN/BR/UK BAR5.1 1
BAR 5.1 MAIN UNIT 12 ABN112550-0002 POWER PCBA US BAR5.1 1
BAR 5.1 MAIN UNIT 15 ABE112770-0001 AMP PCBA BAR5.1 1
BAR 5.1 MAIN UNIT 16 ABE112571-0001 MAIN PCBA BAR5.1 1
BAR 5.1 MAIN UNIT 17 ABE112572-0001 HDMI REPEATER PCBA BAR5.1 1
BAR 5.1 MAIN UNIT 19 ABN112612-0001 WIRELESS PCBA BAR5.1 1
BAR 5.1 MAIN UNIT 21 BPV100153-0001 MAIN L CAP BAR5.1 1
BAR 5.1 MAIN UNIT 24 BRC100082-0001 MAIN RUBBER BAR5.1 8
BAR 5.1 MAIN UNIT 25 BPV110153-0001 MAIN R CAP BAR5.1 1
BAR 5.1 MAIN UNIT 26 ABE112613-0001 JACK PCBA BAR5.1 1
BAR 5.1 MAIN UNIT 29 GZN100004-0001 MAIN WALL MOUNT BKT BAR5.1 2
BAR 5.1 MAIN UNIT 30 BRF100183-0001 MAIN UNIT RUBBER FOOT BAR5.1 3
BAR 5.1 MAIN UNIT 31 ABE112611-0001 DISPLAY PCBA BAR5.1 1
BAR 5.1 MAIN UNIT BD901 RHD210080-0020 BRIDGE GBU1008UL 10A 800V BAR5.1 1
BAR 5.1 MAIN UNIT CN1004 CJA005001-2010 ANTENNA PLUG BAR5.1 1
BAR 5.1 MAIN UNIT F901 KSD020400-0031 FUSE 250V MAIN UNIT BAR5.1 1
BAR 5.1 MAIN UNIT SN3000 RHO138637-2001 PHOTO SENSOR BAR5.1 1
BAR 5.1 MAIN UNIT T901 TSB000023-0018 SW TRANS PQ3230 6+6P 150W 100KHz BAR5.1 1
BAR 5.1 MAIN UNIT USB1000 CJU040032-0002 USB JACK 4P TYPE A BAR5.1 1
BAR 5.1 MAIN UNIT JK1000,JK1002 CJM036014-5030 PHONE JACK 3P BAR5.1 2
BAR 5.1 MAIN UNIT JK1001 CJT200010-0002 FIBER OPTIC JACK BAR5.1 1
BAR 5.1 MAIN UNIT JK5000 CJM035059-1010 PHONE JACK 5P BAR5.1 1
BAR 5.1 MAIN UNIT
JK6000,JK6001,J
K6002,JK6003
CJV020011-0001 HDMI JACK 19P BAR5.1 4
BAR 5.1 MAIN UNIT JK8001 CJU050016-0001 MICRO USB JACK 5P 2
BAR 5.1 MAIN UNIT LD3000 KDD960001-0010 LED DISPLAY 18P BAR5.1 1
BAR 5.1 SURR. SPEAKER SL ABN108002-0015 SURR SPK L ASS'Y BAR5.1 1
BAR 5.1 SURR. SPEAKER SL3 ABN100831-0002 SURR SPK L FRONT HOUSING BAR5.1 1
BAR 5.1 SURR. SPEAKER SL8+SL15 ABN100831-0003 SURR SPK L BATTERY COVER+BATTERY BAR5.1 1
BAR 5.1 SURR. SPEAKER SL9 BPA100069-0001 SURR SPK L REAR HOUSING BAR5.1 1
BAR 5.1 SURR. SPEAKER SL11 BPV100155-0001 SURR SPK END CAP L BAR5.1 1
BAR 5.1 SURR. SPEAKER SL12 BPY100024-0001 SURR SPK END CAP L RING BAR5.1 1
BAR 5.1 SURR. SPEAKER SL13 ABN100831-0006 SURR SPK L INSERT COVER BAR5.1 1
BAR 5.1 SURR. SPEAKER SL14 ABE112631-0001 SURR SPK MAIN L PCBA BAR5.1 1
BAR 5.1 SURR. SPEAKER SL21 ABE112782-0001 WIRELESS L PCBA BAR5.1 1
BAR 5.1 SURR. SPEAKER SR ABN108002-0016 SURR SPK R ASS'Y BAR5.1 1
BAR 5.1 SURR. SPEAKER SR3 ABN100831-0007 SURR SPK R FRONT HOUSING BAR5.1 1
BAR 5.1 SURR. SPEAKER SR9 BPA110069-0001 SURR SPK R REAR HOUSING BAR5.1 1
BAR 5.1 SURR. SPEAKER SR11 BPV110155-0001 SURR SPK END CAP R BAR5.1 1
BAR 5.1 SURR. SPEAKER SR12 BPY110024-0001 SURR SPK END CAP R RING BAR5.1 1
BAR 5.1 SURR. SPEAKER SR13 ABN100831-0009 SURR SPK R INSERT COVER BAR5.1 1
BAR 5.1 SURR. SPEAKER SR14 ABE112632-0001 SURR SPK MAIN R PCBA BAR5.1 1
BAR 5.1 SURR. SPEAKER SR21 ABE112781-0001 WIRELESS R PCBA BAR5.1 1
BAR 5.1 SURR. SPEAKER SR8+SR15 ABN100831-0008 SURR SPK R BATTERY COVER+BATTERY BAR5.1 1
