Follow the same procedure for VOLUME – and VOLUME +. For mute, press both VOLUME + and
VOLUME – button on soundbar and press MUTE button on TV remote control. Press and hold VOLUME+
and SOURCE button on soundbar again for 5 seconds and now your soundbar responds to your TV
remote control*.
*Depending on TV models, the soundbar may not respond to TV remote control.
8. SYSTEM
1. Auto standby
This soundbar automatically switches to standby after 10 minutes of button inactivity and no
audio/video play from a connected device.
2. Auto wake up
The soundbar has a signal detector that can automatically* turn the unit ON when it senses an
audio signal from the last detected connection eg. AUX, Optical, Bluetooth or HDMI source.
*Depending on TV models or source devices, some devices may not be able to wake up the
soundbar automatically.
3. Apply factory settings
Reset this soundbar to the default settings programmed at the factory.
• In any source mode, long press VOLUME -, VOLUME+ and SOURCE button on soundbar top
panel.
4. Software Update
JBL may offer updates for soundbar’s system firmware in the future. If an update is offered, you
can update the firmware by connecting a USB device with the firmware update stored on it to
the USB port on your soundbar. Please visit www.JBL.com or contact JBL call center to receive
more information about downloading update files.
9. PRODUCT SPECIFICATIONS
General
Power Input : 19VDC, 2.0A
Total Maximum Power : 30W
Standby Power Consumption : <0.5W
Soundbar Transducer Size : 2 x 2” woofer \ :2 x 1.5” tweeter
Max SPL : 90db
Frequency Response : 60Hz – 20KHz
Operating Temperature : 0°C – 45°C
Input and Output
HDMI Video Output (with Audio Return Channel) : 1
HDMI HDCP Version : 1.4
Audio inputs : 1 Analog, 1 Optical, \ : Bluetooth, USB
Bluetooth section
Bluetooth Version : 4.2
Bluetooth Frequency Range : 2402MHz – 2480MHz
Max Transmitting Power : 9dbm (EIRP)
Modulation Type : GFSK, π/4 DQPSK, \ : 8DPSK
