13
IRX112BT SPECIFICATIONS
Bottom View Front View Left View Rear View
486
313
258
618
400
299
IRX108BT
IRX112BT
TECHNICAL SPECIFICATIONS
SYSTEM TYPE: Powered 12” two-way
CABINET: Polypropylene with full grille
SENSITIVITY (SPL): 127 dB peak
FREQUENCY RESPONSE (±3 dB): 53 Hz – 20 kHz
POWER RATING: 1300 watts peak
INPUT IMPEDANCE: 10k ohm balanced
COVERAGE PATTERN: 90º (horizontal) x 60º (vertical) nominal
BLUETOOTH: Audio streaming, Bluetooth version 5.0
DSP: 4 presets, feedback suppression, ducking
I/O: 2 XLR/TRS combo mic/line inputs, 1 XLR pass-thru output 35
mm pole socket
MOUNTING: 27.3 lb (12.4 kg)
NET WEIGHT: 11.77 x 15.75 x 24.35 in
DIMENSIONS (D x W x H): (299 x 400 x 618.4 mm)
ORDER SPECIFICATIONS
SHIPPING CARTON (L x W x H): 12.64 x 16.61 x 25.59 in
(321 x 422 x 650 mm)
SHIPPING WEIGHT: 32 lb (14.51 kg)
UPC COD 691991033544
