- 10 -
Product Specifications
MICROPHONE
• Power required/consumption: 5 V 500 mA
• Sample rates: 44.1 kHz / 48 kHz / 96 kHz
• Bit rate: 16 / 24 bit
• Capsules: 6 mm Electret Condenser Microphone
• Polar patterns: Super Cardioid
• Frequency response: 50 Hz - 12 kHz
• Sensitivity: -47 ± 3 dB (1 kHz@1 Pa, 0 dB = 1 v/Pa)
• Maximum SPL: 110 dB
HEADPHONE AMPLIFIER
• Impedance: 16 ohms / 32 ohms
• Power output (RMS): 23 mWrms per channel (Load = 32 ohms)
• THD: <0.5% (Load = 32 ohms)
• Frequency response: 20 Hz - 20 kHz
• Signal to noise: 92 dB (A weighted)
DIMENSIONS - MIC WITH STAND
• Dimensions (L x W x H): 10.5 cm x 10 cm x 18.6 cm / 4.1" x 3.9" x 7.3"
• Weight: 146 g / 0.32 lbs
NOTE:
• Technical specifications are subject to change without prior notice.
