Harman Magnafire Elite Coal - GRATES; GRATE SYSTEM; WARNINGS & SPECIAL INSTRUCTIONS; BLOWER

11
3-90-70745R16_08/13
Section 5
5.1 GRATE SYSTEM
A.Heavy-duty cast iron grate system-Thefunctionsofa
gratesystemaretosupportthecoalandatthesametime
provide air ow through the grates to the coal. Harman®
grateshaveamaximumamountofairowtoproducean
evenburningre.Anotherfunctionistoremovetheashfrom
thecoalbedbygrinding,breaking,orshakingthemthrough
thegrates.Harman® grates provideavariable amountof
grinding action, this action is controlled by the movement
ofalongshakerleverlocatedontheleftsideofthestove.
B. Burns three sizes of anthracite coal-Youcanburnpea,
nut,orstovecoalonthesegrateswithnochangesnecessary.
C. Warnings
1. IMPORTANT! Whenshakingiscomplete,turntheshaker
untilthegratesareatandhorizontal.
2. Keep the ash drawer empty! Ashbuildupcandamage
yourgrates.Ifashbuildsunderandagainstthegrates,itwill
causetheairowtobestoppedorlessened.Thiscondition
willcausewarpingofthegrates.
NOTE: Grates damaged in this way are easily detected by
the great amount of damage caused to them. Please read
your warranty to see limits of liability in cases of abuse.
3. Fresh ashes are hot! Neverputhotashesincontactwith
anyammablematerial.Storehotashesinametalcontainer
outsideofyourhome.Allowtheashestocoolthendispose
ofproperly.
GRATES & WARNINGS
Section 6:
WARNINGS & SPECIAL INSTRUCTIONS
6.1 Blower:
YourHarman®insertisprovidedwithablowersystem.This
system is not only designed to distribute heat throughout
yourhomebutservesacriticalneedinthedesignsystem
oftheinsert.Extremelyhighheatsaregeneratedinsidethe
insertandcandomuchdamagetotheheatexchangerand
bafesystem.Surfacetemperaturesof500degreesF.canbe
associatedwithinternaltemperaturesashighas1000degrees
F.ormore.Temperaturesattheselevelsforextendedperiods
oftime,candamageinternalpartsoftheinsert.Inserts,unlike
freestandingstoves,havenowaytoreleasebuiltupheat
intoyourhomeexceptthroughitsinternalpassages.Free
standingstovesradiatetheirheatfreelyintotheair.
Useoftheblowersisnotonlycriticaltothelifeoftheinsert,
butmuchheatefciencyislostifthedesignofthesystemis
defeatedbynotusingtheblowers.Theheatwhichistrapped
inthereplacemayamounttoasmuchas75%ofthetotal
outputoftheinsert.Thisshouldmakeiteasytoseethatfuel
isbeingwastediftheblowersarenotused.
Harman®hasgonetogreatlengthstodesignthisinsertto
havethebestbalanceoffeatures,looks,andpriceavailable
in the market place today. We also stand strongly behind
ourwarrantyaslongasthewarrantyclaimfallswithinthe
statedliabilityofthatwarranty.Abuseandneglectareterms
outsidetheliabilityofHearth&HomeTechnologiesinmatters
of warranty repair or replacement. To clarify, overring is
consideredabuseandwillnotbeeligibleforwarrantyrepair.
Non-useoftheblowersystemisoneofthemajorcausesof
overringininsertuse.An overre situation isconsidered
toexistwhenthesurfacetemperatureoftheinsertexceeds
500degreesF..
6.2 NOTE:Itisyourresponsibilitytofollowallstateandlocal
codeswheninstallingyourinsert.
6.3 Itissuggestedthatyouhaveaqualiedstoveinstaller
installyourinsert.
6.4Itisyourresponsibilitytomakesurethatproperclearances
tocombustiblematerialsismaintainedwheninstallingyour
insert.
NOTE: Safeclearancetocombustiblesis36inches.Ifyou
haveaammablemantelandproperclearancecannotbe
maintained,ametalshieldmustbeinstalledtoprotectthe
mantel.
6.5Haveyourreplaceandchimneyinspectedbyaqualied
chimneysweeptomakesureyourreplaceandchimneyare
safeandingoodoperatingcondition.
6.6Makesureyourchimneyhasanadequatedraftof0.06
inchesofwatercolumnonadraftmeter.
