Next,installthedraftcontrolontotheashdoor.Thread
theboltthroughtheknobandinstalloneofthenuts.Slip
theremainingendoftheboltthroughthedoorandinstall
thesecondnut.Adjustthenutlocationssothatthedraft
controlstopsopenatabout3/8"fromthedoorsurface,
whilestillbeingabletocloseagainstthedoor.
Thenextstepistoinstalltheglassandtrim.Startbyplacing
theglassframeface-downonaatsurface.Besurethe
glassitselfhasthegaskettinginstalledontheshorterends
only.Thenongasketedtopandbottomallowforair-wash
andsecondaryair.Laytheglassintotheframe,Nowlift
theloaddooroffofthestoveandlayitdownontotheglass
frame.Securetheframetothedoorusing(4)Flange-head
boltsprovided.Whilethedoorisstilllayingat,installthe
toptrimontothedoorwith(2)Hex-headbolts.
Thecoilspringhandlesslipontothelatchesandtheshaker
handle.Pushwhileturningtoinstall.
ASSEMBLY & INSTALLATION
Grates
GrateLink
ShakerBarWeldment
ShakerBlock
(weldedtostove
body)
ShakerHandleMount
-weldedtoshakerbar
ShakerHandle
Thelaststepinassemblyistheshakerhandle.Theshaker
handle is mounted on the lower left front of the insert
withthetwohex-headboltsandlock-washersalreadyin
theshakerhandlemount.Ifyouremovedthegratesfor
installation,makesuretheyareinstalledproperly.Refer
totheillustrationbelow.
