Harman P35I - 4. Distribution Blower; 5. Feeder Body

36
Save These Instructions3-90-775R36_09/15
4. Distribution Blower
Requires no lubrication.
Keep the motor windings and squirrel cage fan free of dust.
Can be wiped clean or vacuumed.
To remove distribution blower:
• Slide the insert body out of the mounting frame.
• Locatetheblowerinthebackoftheunit.You'llneedto
tilt the unit forward for easy access.
• Remove8tekscrewsusinga5/16"driverorwrench.
5. Feeder Body
Wipeorvacuumtoclean.
Useavacuumtoremovenesandsawdust.
Toaccessfeedercleanout;
• Slide the insert body out of the mounting frame.
• Locate the feeder cover from the right side of the unit.
• Loosenthewingnutapproximately3/4ofthewayout
on the stud.
• Pull out on the bottom of the cover then lift upward to
remove.
• Noticethedeectorshieldissittinglooseinthefeeder.
It can be removed by rolling it from under the pusher
arm shaft. Just be sure it is repositioned properly.
• Whenre-installingcover,tightenthewingnuthandtight
only.
Loosen wing nut to remove cover
Vacuumnesfromthisarea
8 screws
