Harman® • P42i Owner’s Manual • 2023 -___ • 03/2322 8742-900A
Service Parts
P42i-TC
Beginning Manufacturing Date: May 2023
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or
distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide
model number and serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM Description COMMENTS PART NUMBER
21.1 Wooden Handle w/Bolt Pkg of 2 1-00-00247
21.2 Door Latch, Painted 3-00-249119P Y
Door Latch Roller Hardware 1-00-05230 Y
21.3 Door Assembly SRV8742-101 Y
21.4 Gasket, 1/2 Round Graphite 20 Ft 1-00-1086415 Y
21.5 Latch Retainer 2-00-674098S
21.6 Glass Clips Pkg of 4 1-00-249140 Y
21.7 Gasket, 3/16 Round w/PSA 10 FT 1-00-1186258229 Y
21.8 Glass w/Gasket 1-00-677000 Y
Additional service parts on following page.
21.8
21.7
21.6
21.5
21.3
21.2
21.1
21.4
#21 Load Door Assembly
To Next Page
